LG OLED65B6P Service Manual

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
+3.3V_NORMAL
USB3_TXM0
ZD4400
OPT
+5V_NORMAL
USB3_DP0
USB_CTL3_0
USB3_TXP0
USB3_RXM0
R4403
4.7K
+5V_USB_3_0
USB3_DM0
USB3_RXP0
C4401
10uF
10V
R4402
10K
+5V_USB_3_0
/USB_OCD3_0
C4400
10uF
10V
C4402
0.1uF
16V
D4400-*1
USB3.0_DIODE_SEMTECH_SUB
EAH61515001
1
8
2
7
3
6
4
5
9
10
D4401-*1
USB3.0_DIODE_SEMTECH_SUB
EAH61515001
1
8
2
7
3
6
4
5
9
10
JK4400-*2
5205-56209
USB3.0_CNPLUS_1.6T
1
VBUS
2
D-
3
D+
4
GND
5
STDA_SSRX-
6
STDA_SSRX+
7
GND_DRAIN
8
STDA_SSTX-
9
STDA_SSTX+
10
SHIELD
JK4400
3AG009S-106N3R6003(1.2T PCB)
EAG63374205
USB3.0_FREEPORT_1.2T
1
VBUS
2
D-
3
D+
4
GND
5
STDA_SSRX-
6
STDA_SSRX+
7
GND_DRAIN
8
STDA_SSTX-
9
STDA_SSTX+
10
SHIELD
R4400
2.2
R4401
2.2
D4400
IP4294CZ10-TBR
USB3.0_DIODE_NXP_MAIN
1
8
2
7
3
6
4
5
9
10
D4401
IP4294CZ10-TBR
USB3.0_DIODE_NXP_MAIN
1
8
2
7
3
6
4
5
9
10
JK4400-*1
SJ113262
EAG63374201
USB3.0_CNPLUS_1.2T
1
VBUS
2
D-
3
D+
4
GND
5
STDA_SSRX-
6
STDA_SSRX+
7
GND_DRAIN
8
STDA_SSTX-
9
STDA_SSTX+
10
SHIELD
IC4400
BD2242G
EAN62871401
3
EN
2
GND
4
OC
1
VIN
6
VOUT
5
ILIM
R4404 14K 1/16W 1%
K2H
15
2015.02.11
USB 2 & 3 26
043.sht
10K(2.63V) --> 4.7K(2.97V)
USB3.0
value change
MAX 1.5A
OCP USB3.0
OCP Current Limit 1.5A
ROHM : 14K
FOR 1.2T PCB
FOR 1.6T PCB
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG OLED65B6P Specifications

General

Screen Type	oled
Wall Mount	300mm x 200mm
Tuner	digital
Screen Size	64.5 inches, 65 inches
Resolution	4k (2160p)
Refresh Rate	60hz
HDR	yes
Built-In Speakers	yes
Surround Sound	other
Speakers Output	40 watts
Number Of Speakers	4
HDMI Ports	4
HDMI 2.1 Ports	0
USB Ports	3
RF Antenna	yes
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	webos
Streaming Services	netflix, youtube
Voice Assistant	other
Remote Control	magic
3D	no
Power Consumption	200 kilowatt hours
Depth with Stand	8.9 inches
Height with Stand	34.7 inches
Width with Stand	57.1 inches
Net Weight with Stand	57.1 pounds
Depth without Stand	1.9 inches
Height without Stand	33 inches
Net Weight without Stand	49.8 pounds
