LG OM7560 - Connector Voltage

CONNECTOR VOLTAGE
3-73 3-74
Location
Connector
Name
Pin No. Pin Name Voltage(V)
CN801 USB1 (2.0)
1 GND 0.00
2 D+ 0.07
3 D- 0.07
4 USB 5V 5.07
5 GND 0.00
6 GND 0.00
CN802 USB2 (1.1)
1 GND 0.00
2 D+ 0.22
3 D- 0.23
4 USB 5V 5.07
5 GND 0.00
6 GND 0.00
CN803
FROM TOP
 MAIN
1 D2- 0.01
2 D2+ 0.07
3 DGND 0.00
4 USB_5V 5.07
5 USB_5V 5.07
6 USB_5V 5.07
7 DGND 0.00
8 D1- 0.03
9 D1+ 0.03
10 DGND 0.00
CN804
MAIN  FRONT
1 OUT4 0.18
2 OUT5 0.18
3 OUT3 0.18
4 OUT6 0.18
5 OUT2 0.18
6 OUT7 0.18
7 OUT1 0.18
8 OUT8 0.19
9 OUT0 0.18
10 OUT9 0.19
11 GND 0.00
12 VFD_12V 11.95
13 3.3VA 3.31
14 DVCC_5V 4.90
15 DVCC_3.3V 3.26
16 DVCC_5V 4.91
17 VFD_CLK 3.26
18 VFD_STB 3.10
19 VFD_DO 3.09
20 GND 0.00
21 LANDING_GEAR 1.96
22 KEY2 3.29
23 KEY1 3.29
24 MIC_VOL_A 3.26
25 MIC_VOL_B 3.26
26 SCRATCH_A 3.25
27 SCRATCH_B 0.00
28 FILE_S_B 3.26
29 FILE_S_A 0.00
30 MAIN_VOL_B 3.29
31 MAIN_VOL_A 3.29
32 F_LED_12V 11.80
33 GND 0.00
Location
Connector
Name
Pin No. Pin Name Voltage(V)
CN851
MAIN
 SPACE
LIGHTING
1
SPACE_EXP_DAT 3.11
2
SPACE_EXP_CLK 0.00
3 LAT 0.00
4 DVCC_3.3V 3.25
5 DGND 0.00
6 LED_5V_M 5.09
CNA301
MAIN  FRONT
1 DVCC_3.3V 3.26
2 3.3VA 3.29
3 DGND 0.00
4 RMC_SIG 3.17
5 MIC_DET 3.24
6 MIC_SIG1 0.00
7 DGND 0.00
8 MIC_SIG2 0.00
9 PT-DET 3.26
10 PT-RCH 0.00
11 PTGND 0.00
12 PT-LCH 0.00
CNS501
MAIN
 SPAKER
LIGHTING
1 WHITE 4.94
2 GND 0.00
3 WOOFER_R 5.01
4 WOOFER_G 2.04
5 WOOFER_B 0.77
