LG OM7560 - 3 Base Assembly Sled; Gear Feed; Gear Middle; Gear Rack

4-4
3. Base Assembly Sled (Fig. 4-3)
1) Release 4 Screw(S2).
2) Disconnect the FFC Connector(C1)
3-1. Gear Feed
3-2. Gear Middle
3-3. Gear Rack
4. Rubber Rear (Fig. 4-3)
BASE PU
RUBBER DAMPER
RUBBER DAMPER
RUBBER DAMPER
Distinguish upper and
lower sides
(Assemble with care)
Distinguish upper and
lower sides
(Assemble with care)
RUBBER DAMPER
Fig. 4-3
(S2)
(S2)
(S2)
(S2)
GEAR RACK
GENERAL PICK UP ASSEMBLY
SPINDLE MOTOR ASSEMBLY
