LG PA11WS User Manual

25
OPERATION
EN
Setting the On/Off Timer
This function sets the air conditioner to turn on/
off automatically at desired time.
On/Off Timer can be set together.
Setting the On Timer
1
Press button repeatedly.
• The icon below blinks at the bottom of the
display screen.
2
Press or button to select the
minutes.
3
Press button to finish.
• After setting the timer, current time and
icon are displayed on the display
screen indicating that the desired time is
set.
Canceling the On Timer
1
Press button repeatedly.
• The icon below blinks at the bottom of the
display screen.
2
Press button to cancel the setting.
Setting the Off Timer
1
Press button repeatedly.
• The icon below blinks at the bottom of the
display screen.
2
Press or button to select the
minutes.
3
Press button to finish.
• After setting the timer, current time and
icon are displayed on the display
screen indicating that the desired time is
set.
Canceling the Off Timer
1
Press button repeatedly.
• The icon below blinks at the bottom of the
display screen.
2
Press
Canceling the Timer Setting
• Press button to cancel all timer settings.
button to cancel the setting.

LG PA11WS Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency class (cooling)	A+
Energy efficiency class (heating)	-
Hourly energy consumption (cooling)	- kWh
Type	Monobloc mobile air conditioner
Hose length	1.5 m
Noise level	53 dB
Hose diameter	150 mm
Compressor type	Rotary
Inverter technology	Yes
Refrigerating medium	R290
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.2 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Fan
Refrigerating medium weight	220 g
Cooling capacity in watts (max)	- W
Cooling capacity in watts (nominal)	2500 W
Cooling energy efficiency (EER, W/W)	3.1
Product color	White

Weight and Dimensions

Depth	460 mm
Width	493 mm
Height	773 mm
Weight	34200 g
Package depth	504 mm
Package width	562 mm
Package height	822 mm
Package weight	37200 g
