12
Designs and specifications are subject to change without notice.
Specifications
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 3.1 kg
External dimensions
(WxHxD) (202 x 307 x 292) mm
Operating temperature 5
o
C to 35
o
C
Operating humidity 5% to 85 %
Tuner
FM Tuning Range 87,5 to 108,0 MHz or
87,50 to 108,00 MHz
AM Tuning Range 522 to 1620 kHz or 522 to 1710 kHz
(optional) or 520 to 1710 kHz
Amplifier
Output Power 55 W + 55 W
T.H.D 10 %
Frequency Response 42 to 20 000 Hz
Signal-to-noise ratio 75 dB
CD
Frequency response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Speakers (RAS114B) (RAS114F)
Type 2 Way 2 Speaker
Impedance 4 Ω
Rated Input Power 55 W
Max. Input Power 110 W
Net Dimensions (WxHxD) (215 x 309 x 232) mm
Net Weight (1EA) 2.6 kg
Troubleshooting
Symptom Cause Correction
General
No power.
No sound.
The power cord is not plugged in.
Check whether electricity failed.
Check whether you select right function.
Plug in the power cord.
Check the condition by operating other
electronic devices.
Press FUNCTION and check the
selected function.
CD
The unit does not
start playback.
An unplayable disc is inserted.
The disc is dirty.
Insert a playable disc.
Clean the disc.
RADIO
Radio stations
cannot be tuned in.
The antenna is positioned or connected
poorly.
Connect the antenna securely.
Remote control
The remote control
does not work
properly.
The remote control is too far from the
unit.
There is an obstacle in the path of the
remote control and the unit.
The battery in the remote control is
exhausted.
Operate the remote control within about
23 ft (7 m).
Remove the obstacle.
Replace the battery with new one.
RAD114-A0U-DNGAFLK-ENG.indd 12RAD114-A0U-DNGAFLK-ENG.indd 12 2010.4.5 3:24:27 PM2010.4.5 3:24:27 PM
