LG RM2 User Manual

Connecting10
Connecting
2
y
If you use a tripod, use the tripod only for
speaker.
y
Before buying a tripod, check the
specications for maximum bearing load of
the center column.
(Unit’s net weight : about 12.3 kg)
(B)
(A)
35 mm
y
Use tripod as below :
(A) From tripod’s center to tripod’s leg :
above 600 mm.
(B) From top of tripod to bottom of tripod :
below 900 mm.
(C) Tripod net weight : over 3.9 kg
y
For safe use set the tripod as low as
possible.
y
You should pull the center column to the
maximum only in case of need.
y
Mount only one unit on each tripod.
y
Do not try to extent the tripod legs beyond
it’s allowed range.
y
Make sure the tripod is correctly assembled
and all its components are tightly
connected.
y
Do not try to assemble the tripod if parts
are missing or defective.
y
After installation, make sure the unit is set
up rmly on the tripod.
y
Do not place the unit on anything unstable
where it might accidentally fall over.
y
Add weight such as sand bags around the
tripod legs to prevent the tripod from falling
over.
,
Note
y
You should limit people around the unit
while its on a tripod. Otherwise it may result
in an accident and may cause personal injury
and/or property damage.
y
Standing on the stool to reach unit’s control
panel is risky and might lead to injuries.
y
Do not put or attach other objects on the
tripod.
y
Do not shake or push the unit when the
tripod is installed.
y
Refrain from moving around the tripod after
unit is installed.
y
Remove all connected cables to the unit
on the tripod before moving the tripod or
adjusting its height.
y
When transporting or moving the unit,
always use two or more people.
y
When you use the tripod, use an extension
cord. Always be careful with the movement
of the cable.
y
It is prohibited to use this unit outside.
(Indoor use only)
y
Do not expose the unit to excessive dust,
vibrations, extreme cold or heat (such as in
direct sunlight or near a heater) to prevent
the possible disgurement of the panel or
damage to the internal components.
y
When using the external input cable (Mic,
etc.) after installing the unit on the tripod,
external input cable can cause the unit to
fall down.
y
Watch out because people can trip over the
input cable (Mic, etc.) connected the unit.
y
Always be careful not to trip over the unit.
,
Note

LG RM2 Specifications

General

Woofer	Yes
Speaker type	1-way
Number of drivers	-
Speaker placement	Floor, Stand-mountable
Audio output channels	1.0 channels
Impedance	3 Ω
Sensitivity	102 dB
RMS rated power	- W
Product color	Black
Volume control	Rotary
Recommended usage	DJ
USB connector type	USB Type-A
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
AC input voltage	111 - 240 V
Power source type	AC
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Package type	Box
Package depth	508 mm
Package width	742 mm
Package height	402 mm
Package weight	14444 g

Weight and Dimensions

Depth	385 mm
Width	430 mm
Height	655 mm
Weight	12000 g
