LG RM2 - Technical Specifications; General and Environmental Specifications; Audio Input;Output Specifications; System and Amplifier Performance

5 Appendix
Appendix 19
Appendix
5
General specifications
General
Power requirements
Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Dimensions (W x H x D)
Approx. 430 mm X 655 mm X 385 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 % RH
Inputs
Analog audio in (LINE IN) 0.4 Vrms (1 kHz, 0 dB), 600
Ω
, RCA jack (L, R)
Analog audio out (LINE OUT) 1.0 Vrms (1 kHz, 0 dB), 600
Ω
, RCA jack (L, R)
Microphone (MIC 1/2) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
System
Frequency Response 60 to 20,000 Hz
Signal-to-noise ratio More than 70 dB
Dynamic range More than 70 dB
Bus Power Supply (USB) 5 V
0
500 mA
Amplier (RMS Output power)
Total output 80 W (3
Ω
at 1 KHz, 10 % THD)
y
Design and specications are subject to change without notice.
