2-44
ELECTRICAL TROUBLESHOOTING GUIDE
No 3.3 VA
Is the VCC supplied
to IC155 pin3?
Check 5.5 VA on SMPS board.
YES
YES
NO
Check IC155 and replace.
No 3.3 V
Is the VCC supplied
to IC156 pin3?
Check 5.5 VA on SMPS board.
YES
YES
NO
Is there signal
at IC156 pin2?
Check IC101 pin25 (DCDC33_CTRL).
Check IC156 and replace.
YES
NO
2. POWER SUPPLY ON MAIN BOARD
58
60
