LG S95A1-D User Manual

2-622-61
Location Value Capacitor (uF) Voltage Spec
100V-10% 240V/50Hz+10%
Measured voltage Measured voltage
SMPS Board
C905 68uF 460V 154.5V 310V
C906 68uF 460V 154.5V 310V
C911 100uF 50V 25.9V 26V
C919 1uF 50V 20.9V 20.9V
C928 1uF 50V 20.2V 20.3V
C951 1000uF 35V 25.9V 25.9V
C952 1000uF 35V 25.9V 25.9V
C953 1000uF 35V 25.9V 25.9V
Part Designator Voltage Spec Pin
Mearsured Voltage
#79 / #1
Remarks
MAIN
CN100 WLS_3V3 1 3.62 Wireless
CN104
VCC_5V 13 5.08
FRONT6.2VA 14 6.17
3.7VA 15,16 3.67
CN105
6.2VA 1 6.18
HDMI
3.7VA 2 3.67
VCC_5V 5 5.07
D_3.3V 8 3.29
CN200 WIFI_3.5VA 6 3.67 WIFI
CN300 25VA 1,2,3 25.3 SMPS
CN2011 3.3VA 1 3.28 BT
HDMI CN804
6.2VA 1 6.18
MAIN
3.7VA 2 3.67
VCC_5V 5 5.07
D_3.3V 8 3.29
FRONT
CN400
VCC_5V 13 5.08
MAIN6.2VA 14 6.17
3.7VA 15,16 3.66
CN401
F_3.3VA 4,6 3.44
LCDVCC_5V 7 5.07
6.2VA 10 5.78
2. CAPACITORS 3. CONNECTORS
Designator Voltage Spec Mearsured Voltage
Main & AMP Board
C7000 25V 25.4
C7039 25V 25.4
C7085 25V 25.4
C7088 25V 25.4
C7134 25V 25.4
C7137 25V 25.4
C7183 25V 25.4
