Specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D)
Approx. 650.0 mm x 79.0 mm x 94.0 mm with foot
(25.6 inch x 3.1 inch x 3.7 inch)
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Audio, PCM
Inputs
OPT. IN (Digital audio in) 0 dBfs, Optical jack x 1
PORT. IN (Portable in) 0.4 Vrms (3.5 mm stereo jack) x 1
Amplier (RMS Output power)
Total 40 W RMS
Front 20 W RMS x 2 (4
Ω
at 1 kHz, 10% THD)
y
Designs and specications are subject to change without prior notice.
