LG SNC4R Service Manual

1-11
Copyright © 2021 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
SPECIFICATIONS
• GENERAL
Power consumption Refer to the main label.
Networked standby : 0.5 W
(If all network ports are activated.)
AC adapter  Model : DA-38A25
 Manufacturer : Asian Power Devices Inc.
 Input : 100 - 240 V ~ 50 - 60 Hz
 Output : 25 V 1.52 A
Dimensions (W x H x D) Approx. 890.0 mm x 57.0 mm x 85.0 mm With foot
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V 500 mA
Available Digital Input Audio
Sampling Frequency 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Audio, DTS Digital Surround, PCM
• INPUT/OUTPUT
OPTICAL IN 3 V (p-p), Optical jack x 1
• AMPLIFIER (RMS Output)
Total 300 W RMS
Front 50 W RMS x 2 (4 Ω at 1 kHz, THD 10 %)
Subwoofer 200 W RMS (3 Ω at 80 Hz, THD 10 %)
• WIRELESS SUBWOOFER
Power requirements Refer to the main label on the wireless subwoofer.
Power consumption Refer to the main label on the wireless subwoofer.
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 200 W
Max. Input Power 400 W
Dimensions (W x H x D) Approx. 171.0 mm x 390.0 mm x 261.0 mm
SPJ4-S (SPJ4-S, S65S3-S)
• WIRELESS RECEIVER
Power requirements Refer to the main label on the wireless receiver.
Power consumption Refer to the main label on the wireless receiver.
Rear 70 W RMS x 2 (3 Ω at 1 kHz, THD 10%)
Dimensions (W x H x D) Approx. 60.0 mm x 220.0 mm x 175.0 mm
(2.4 inch x 8.7 inch x 6.9 inch)
• REAR SPEAKERS (EACH)
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 70 W RMS
Max. Input Power 140 W RMS
Dimensions (W x H x D) Approx. 100.0 mm x 140.0 mm x 100.0 mm
(3.9 inch x 5.5 inch x 3.9 inch)
• Designs and specifications are subject to change without prior notice.

LG SNC4R Specifications

General

Audio decoders	DTS Digital Surround, Dolby Digital
Equalizer modes	AI Sound Pro, Bass Blast+, Movie, Standard
RMS rated power	420 W
Audio output channels	4.1 channels
Rear speaker RMS power	120 W
Front speakers RMS power	100 W
Night mode	Yes
Product color	Black
Audio formats supported	LPCM, MP3, WMA
Wi-Fi	No
HDMI ports quantity	-
Connectivity technology	Wired & Wireless
Digital audio optical in	1
Subwoofer type	Active subwoofer
Subwoofer connectivity	Wireless
Cables included	Optical
Number of products included	1 pc(s)
Soundbar power consumption	23 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	33 W
Soundbar speaker RMS power	- W
Package type	Box
Package depth	373.38 mm
Package width	947.42 mm
Package height	223.52 mm
Package weight	12111 g

Weight and Dimensions

Depth	86.4 mm
Width	891.54 mm
Height	58.42 mm
Soundbar weight	2358.7 g
Subwoofer depth	261.6 mm
Subwoofer width	172.7 mm
Subwoofer height	391.2 mm
Subwoofer weight	5307 g
