Connecting 23

Connecting

Optional equipment

connection

OPTICAL IN connection

Connect an optical output jack of external devices to

the OPTICAL IN jack.

Optical cable

To the optical output

jack of external device

1. Connect the OPTICAL IN jack on the back of the

unit to optical out jack of your external device.

2. Select the input source to OPT by pressing F

repeatedly.

You can see “OPT” on the display window if

connecting normally between this unit and your

device.

Before connecting the optical cable, be sure to

remove the protection plug cover if your cable

has the cover.

Note

USB connection

Connect USB memory device to the USB port on the

back of the unit.

For more information of playing les on a USB, refer

to the page 26.

Removing the USB Device from the unit.

Choose a different function/mode.

2. Remove the USB device from the unit.

Compatible USB devices

MP3 Player: Flash type MP3 player.

USB Flash Drive: Devices that support USB 1.1.

The USB function of this unit does not support

some USB devices.
