LG SPJ2B-W - Circuit Voltage Chart

CIRCUIT VOLTAGE CHART
3-21 3-22
Location No. Pin Number Specifi cation Real Value
MAIN Board
CN300
1 IR 3.1-3.6 V 3.3 V
2 GND 0 V 0 V
3 BK33 3.1-3.6 V 3.3 V
4 USB IN_LED 0-3.6 V 0-3.2 V
5 Audio IN_LED 0-3.6 V 0-3.2 V
6 BT_LED 0-3.6 V 0-3.2 V
7 Optical_LED 0-3.6 V 0-3.2 V
8 STANDBY LED 0-3.6 V 0-3.2 V
CN303
1 KEY1 0-3.6 V 0.3-3.3 V
2 KEY1 0-3.6 V 0.3-3.3 V
3 GND 0 V 0 V
4 GND 0 V 0 V
CN500
1 DCIN22V 8-27 V 23.1 V
2 DCIN22V 8-27 V 23.1 V
3 DCIN22V 8-27 V 23.1 V
4 DCIN22V 8-27 V 23.1 V
5 GND 0 V 0 V
6 GND 0 V 0 V
7 GND 0 V 0 V
8 GND 0 V 0 V
9 FL+ 4-15V V 11.5 V
10 FL+ 4-15V V 11.5 V
11 FL- 4-15V V 11.5 V
12 FL- 4-15V V 11.5 V
CN501
1 FR+ 4-15 V 11.5 V
2 FR- 4-15 V 11.5 V
KEY Board
CN800
1 KEY 0.3.6 V 0.3-3.3 V
2 KEY 0-3.6 V 0.3-3.3 V
3 GND 0 V 0 V
4 GND 0 V 0 V
LED Board
CN801
1 IR1 3.1-3.6 V 3.3 V
2 GND 0 V 0 V
3 BK3V3 3.1-3.6 V 3.3 V
4 USB LED 0-3.6 V 0-3.2 V
5 AUDIO LED 0-3.6 V 0-3.2 V
6 BT LED 0-3.6 V 0-3.2 V
7 Optical LED 0-3.6 V 0-3.2 V
8 STANDBY LED 0-3.6 V 0-3.2 V
