LG SPJ2B-W Service Manual

CIRCUIT VOLTAGE CHART
4-11 4-12
Location No. Pin Number Specifi cation Real Value
CN201
1 SUB- 0~12.33 V 12.33 V
2 SUB+ 0~12.33 V 12.33 V
CN203
1 SDA 3.1-3.5 V 3.28 V
2 SDL 3.1-3.5 V 3.28 V
3 REST 3.1-3.5 V 3.27 V
4 GND 0 V 0 V
5 3.3V 3.1-3.5 V 3.31 V
