Only for training and service purposes.

2-162-15

• Cabinet and main frame parts list

RUN DATE : 15-April-2022

S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS

ASSEMBLY PARTS

A41 COV36774901 Case,Outsourcing anam case Case case bottom -

A42 COV36776201 Cover Assembly,Outsourcing anam top cover assy top cover

A46

COV36809602

PCB Assembly,Main,Outsourcing

ANAM VHSSPM2BKSVCYZ PCB Assemb

A47 COV36809801

PCB Assembly,Power,Outsourcing

ANAM VOP13192B_SMPS PCB Assemb

A51 COV36810301 PCB Assembly,RF,Outsourcing ANAM VHSSP2BKSVCWZ PCB Assembl

A80L COV36775301 Cover,Outsourcing anam cover left Cover cover si

A80R COV36775101 Cover,Outsourcing anam cover side Cover cover si

INDIVISUAL PARTS

250 COV36812501 Speaker Unit,Outsourcing ANAM VAS50FP402SEZ Speaker Uni

251 COV36812601 Speaker Unit,Outsourcing ANAM VAS10LD401SEZ Speaker Uni

252 COV36809501 PCB,LED,Outsourcing ANAM VHSSP2BKSVCZZ PCB,LED SP2

253 COV36810901 HARNESS,Outsourcing ANAM VHSSP2BKSVCVZ HARNESS SP2

254 COV36809901

PCB Assembly,Remocon,Outsourci

ANAM VOP13190B-3 PCB Assembly,

255 COV36809001 Cover,Outsourcing anam cover jack Cover cover ja

256 COV36812701 Speaker Unit,Outsourcing ANAM VAS86YS403SXZ Speaker Uni

257 COV36812801

PCB Assembly,Keypad,Outsourcin

ANAM VHSSP2BKSVCXZ PCB Assembl

258 COV36808801 Holder,LED,Outsourcing anam holder led Holder,LED hol

CABLES

CABLE1 COV36811201 FFC Cable,Outsourcing ANAM CWC4C4A10A060B08J01 FFC C

CABLE2 COV36811101 HARNESS,Outsourcing ANAM CWBSP2CN101 HARNESS SP2

CABLE3 COV36811001 HARNESS,Outsourcing ANAM CWBSP2CN502 HARNESS SP2 S
