LG StudioWorks 585E - Page 24

DATE: 2003. 02. 19.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C913 0CE476CK638 “47UF SHL,SD 50V M FM5 TP 5”
C914 0CZZTFT001P ECQB1H153JM3 153J 50V TP5.0
C915 0CK6810K515 680P 50V K B TS
C917 0CK1020K515 1000PF 50V K B TR
C918 0CK1040K945 0.1UF 50V Z F TR
C941 0CE108CD618 1000UF SHL 10V M FL TP5
C942 0CE107CF638 “100UF SHL,SD 16V M FM5 TP 5”
C943 0CK56101515 560P 1KV K B TS
C944 0CZZTCB002C DCF472M59Y5UQ7DK7D HONGMING
C945 0CK5610W515 560P 500V K B TS
C946 0CZZTCB002C DCF472M59Y5UQ7DK7D HONGMING
C951 0CE108CF630 1000UF SHL 16V M FM5 BULK
C952 0CE227CH638 “220UF SHL,SD 25V M FM5 TP 5”
C953 0CE107CF638 “100UF SHL,SD 16V M FM5 TP 5”
C954 0CE108CF630 1000UF SHL 16V M FM5 BULK
C971 0CE476CN618 47UF SHL 100V M FL TP5
C999 0CE227EL630 220UF KMG 63V M FM5 BULK
D201 0DLLT0089AA LITEON LTL-1BEDJ-0C2 TP GREE
D301 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D302 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D303 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D304 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D305 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D306 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D307 0DS124409AA 1SS244 TP ROHM KOREA
D308 0DS124409AA 1SS244 TP ROHM KOREA
D309 0DS124409AA 1SS244 TP ROHM KOREA
D310 0DS124409AA 1SS244 TP ROHM KOREA
D311 0DS124409AA 1SS244 TP ROHM KOREA
D312 0DS124409AA 1SS244 TP ROHM KOREA
D313 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D314 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D399 0DR140059AD 1N4005 GULF TP DO41 600V 1A
D402 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D404 971-0054 TIN 50MM TAPING
D512 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D610 0DR100009CD RGP10G-1021 TIWAN SEMI TP DO
D702 0DS124409AA 1SS244 TP ROHM KOREA
D703 0DRGF00080A GUR460 GULF BK DO201AD 600V
D704 0DR150001AA DTV1500MFP ST SGS-THOMSON TO
D705 0DR100009CD RGP10G-1021 TIWAN SEMI TP DO
D706 0DR150001AA DTV1500MFP ST SGS-THOMSON TO
D707 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D709 971-0054 TIN 50MM TAPING
D710 0DRGF00109B GUF10G-28A GULF TP DO41 400V
D711 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D712 0DR100009CD RGP10G-1021 TIWAN SEMI TP DO
D713 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D714 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D715 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D716 0DR140059AD 1N4005 GULF TP DO41 600V 1A
D717 0DR140059AD 1N4005 GULF TP DO41 600V 1A
D718 0DR140059AD 1N4005 GULF TP DO41 600V 1A
D719 0DR100009DA RGP10J TP GULF SEMICONDUCTOR
D720 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D721 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D724 0DR140059AD 1N4005 GULF TP DO41 600V 1A
D725 0DRGF00069A SB140 GULF TP DO41 40V 1A 40
D801 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D802 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
DATE: 2003. 02. 19.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D900 0DRGF00090A GBL06 GULF BK GBL 600V 4A 12
D902 0DR153979BA 1N5397GP TP GULF SEMICONDUCT
D904 0DR100009CD RGP10G-1021 TIWAN SEMI TP DO
D905 0DRGF00109A GUF10M GULF TP DO41 1000V 1A
D906 0DR100009CD RGP10G-1021 TIWAN SEMI TP DO
D908 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D910 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D911 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D941 0DR100009LD UG1D GULF TP DO41 200V 1A 40
D942 0DR100009CD RGP10G-1021 TIWAN SEMI TP DO
D951 0DRTW00044B UG2DL-1021 TIWAN SEMI BK DO1
D952 0DS141489AB 1N4148 TP GRANDE DO-34 500MW
D961 0DRTW00060A SF38GL-1121 TIWAN SEMI BK DO
D971 0DR100009DA RGP10J TP GULF SEMICONDUCTOR
ZD201 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD202 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD203 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD402 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD403 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD404 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD405 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD407 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500
ZD701 0DZ120009BF GDZJ12B TP GRANDE DO34 0.5W
ZD702 971-0054 TIN 50MM TAPING
ZD902 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW
IC301 0IPRPWL001A “6805-N160WT-87A WELTREND 16,”
IC302 0IPRPSG014A “STV9211 SGS-THOMSON 20P,DIP”
IC303 0IPRPSG004B “STV9556 SGS-THOMSON 11P,CLIP”
IC401 0IZZTSZ255A SS OTP 42PIN SDIP ST 6KEY CB
IC402 0ISG240860A M24C08-BN6 8DIP BK 8K SERIAL
IC601 0IPRPSG016A “STV9302A SGS-THOMSON TO220,7”
IC701 0IPRPSG017A “STV6888 SGS-THOMSON 32P,SDIP”
IC901 0ISS384200A KA3842B (PWM)
FB201 6210TCE003J BAS2550T BO SUNG 2550MM AXIA
FB304 6210TCE003J BAS2550T BO SUNG 2550MM AXIA
FB305 6210TCE003A BRD3510B BO SUNG 3510MM RADI
FB314 6210TCZ001J BAS3550T0(125-022J) BO SUNG
FB315 6210TCZ001J BAS3550T0(125-022J) BO SUNG
FB316 6210TCZ001J BAS3550T0(125-022J) BO SUNG
FB401 971-0054 TIN 50MM TAPING
FB402 6210TCE003K BAS3550T BO SUNG 3550MM AXIA
FB403 6210TCE003K BAS3550T BO SUNG 3550MM AXIA
FB701 6210TCE003L BAS3580T BO SUNG 3580MM AXIA
FB703 6210TCE003L BAS3580T BO SUNG 3580MM AXIA
FB705 971-0054 TIN 50MM TAPING
FB903 6210TCE003P BRS2550B BO SUNG 2550MM RADI
FB904 971-0054 TIN 50MM TAPING
FB905 6210TCE003P BRS2550B BO SUNG 2550MM RADI
FB921 6210TCE003A BRD3510B BO SUNG 3510MM RADI
FB922 6210TCE003L BAS3580T BO SUNG 3580MM AXIA
FB951 971-0054 TIN 50MM TAPING
L301 0LA0560K119 0.56UH K 2.3*3.4 TP
L302 0LA0560K119 0.56UH K 2.3*3.4 TP
L303 0LA0560K119 0.56UH K 2.3*3.4 TP
L304 0LA1000K119 100UH K 2.3*3.4 TP
L702 6140TBZ025C DR14*20 150UH 0.12*25MM 51T
- 24 -
DIODEs
ICs
COILs & COREs
