LG StudioWorks 585E - Page 25

DATE: 2003. 02. 19.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L703 6140TYZ010E “LX31 GET DR14*15-C5.2,18.5T,”
L705 6140TBZ026C DR15*18-C9.8 100UH 0.1*30MM
L901 6200TZZ004A SQE2626 NAMYANG BK L/FILTER
L903 6200J00003A RH3.5*5.0 BOSUNG TP
Q301 0TR100809AA KSC1008C-Y TP SAMSUNG TO92
Q501 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO
Q502 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q503 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q701 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q703 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q704 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO
Q705 0TR100809AA KSC1008C-Y TP SAMSUNG TO92
Q706 0TRFC10008A FJAF5804(TU) FAIRCHILD ST TO
Q707 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q708 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q709 0TR141300AB KTD1413 BK KEC TO220I S NPN
Q711 0TF630000DA IRF630A BK SAMSUNG 200V 9A T
Q712 0TF630000DA IRF630A BK SAMSUNG 200V 9A T
Q713 0TF630000DA IRF630A BK SAMSUNG 200V 9A T
Q714 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q715 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q716 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q717 0TR100809AA KSC1008C-Y TP SAMSUNG TO92
Q719 0TF630000DA IRF630A BK SAMSUNG 200V 9A T
Q799 0TR920009AB KSP92 TP SAMSUNG TO92 HIGH V
Q901 0TF760000AD SSS7N60B FAIRCHILD ST TO220F
Q903 0TR100809AA KSC1008C-Y TP SAMSUNG TO92
Q941 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q942 0TR928009AB KSA928A-Y TP SAMSUNG TO92L P
Q951 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q952 0TR928009AB KSA928A-Y TP SAMSUNG TO92L P
Q953 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
R151 0RD1102Q609 11K 1/4W(3 5% TA52
R152 0RD1002A609 10K OHM 1/2 W (7.0) 5% TA52
R153 971-0054 TIN 50MM TAPING
R157 0RD1302Q509 13K OHM 1/4 W (3.4) 2% TA52
R158 971-0054 TIN 50MM TAPING
R201 0RD1001Q609 1K 1/4W(3 5% TA52
R202 0RD0912Q609 91 OHM 1/4 W (3.4) 5% TA52
R203 0RD2200Q609 220 1/4W(3 5% TA52
R204 0RD4300Q609 430 OHM 1/4 W(3.4) 5.00% TA5
R205 0RD1001Q609 1K 1/4W(3 5% TA52
R206 0RD0912Q609 91 OHM 1/4 W (3.4) 5% TA52
R207 0RD4300Q609 430 OHM 1/4 W(3.4) 5.00% TA5
R208 0RD2200Q609 220 1/4W(3 5% TA52
R209 0RD9100Q609 910 1/4W(3 5% TA52
R210 0RD2200Q609 220 1/4W(3 5% TA52
R211 0RD2200Q609 220 1/4W(3 5% TA52
R301 0RD0752Q609 75 1/4W(3 5% TA52
R302 0RD0752Q609 75 1/4W(3 5% TA52
R303 0RD0752Q609 75 1/4W(3 5% TA52
R304 0RD3001Q609 3K 1/4W(3 5% TA52
R305 0RD1001Q609 1K 1/4W(3 5% TA52
R307 0RD6200Q609 620 1/4W(3 5% TA52
R308 0RD6803Q609 680K 1/4W(3 5% TA52
R309 0RN6201F409 6.20K 1/6W 1% TA52
DATE: 2003. 02. 19.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R311 0RD0271Q609 2.70 1/4W(3 5% TA52
R312 0RD2001Q609 2K 1/4W(3 5% TA52
R313 0RD1000Q609 100 1/4W(3 5% TA52
R314 0RD6800Q609 680 1/4W(3 5% TA52
R315 0RD6800A609 680 OHM 1/2 W (7.0) 5% TA52
R317 0RD1001Q609 1K 1/4W(3 5% TA52
R319 0RD1000Q609 100 1/4W(3 5% TA52
R320 0RD1000Q609 100 1/4W(3 5% TA52
R321 0RD0152Q609 15 1/4W(3 5% TA52
R322 0RD0152Q609 15 1/4W(3 5% TA52
R323 0RD0152Q609 15 1/4W(3 5% TA52
R324 0RD3300Q609 330 1/4W(3 5% TA52
R325 0RD3300Q609 330 1/4W(3 5% TA52
R326 0RD3300Q609 330 1/4W(3 5% TA52
R327 0RD3300Q609 330 1/4W(3 5% TA52
R331 0RD0512Q609 51 1/4W(3 5% TA52
R332 0RD0512Q609 51 1/4W(3 5% TA52
R333 0RD0512Q609 51 1/4W(3 5% TA52
R335 0RD0271Q609 2.70 1/4W(3 5% TA52
R336 0RD1000Q609 100 1/4W(3 5% TA52
R337 0RD1000Q609 100 1/4W(3 5% TA52
R351 0RD2200A609 220 OHM 1/2 W (7.0) 5% TA52
R352 0RD2200A609 220 OHM 1/2 W (7.0) 5% TA52
R353 0RD2200A609 220 OHM 1/2 W (7.0) 5% TA52
R354 0RD0392A609 39 OHM 1/2 W (7.0) 5% TA52
R382 0RD1000Q609 100 1/4W(3 5% TA52
R383 0RD1000Q609 100 1/4W(3 5% TA52
R401 0RD1000Q609 100 1/4W(3 5% TA52
R402 0RD5600Q609 560 1/4W(3 5% TA52
R405 0RD2001Q609 2K 1/4W(3 5% TA52
R406 0RD2001Q609 2K 1/4W(3 5% TA52
R407 0RD1300Q609 130 1/4W(3 5% TA52
R408 0RD1300Q609 130 1/4W(3 5% TA52
R409 0RD1000Q609 100 1/4W(3 5% TA52
R410 0RD1000Q609 100 1/4W(3 5% TA52
R411 0RD3002Q609 30K 1/4W(3 5% TA52
R414 0RD4701Q609 4.70K 1/4W(3 5% TA52
R417 0RD1000Q609 100 1/4W(3 5% TA52
R418 0RD1002Q609 10K 1/4W(3 5% TA52
R419 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R424 0RD2200Q609 220 1/4W(3 5% TA52
R425 0RD4701Q609 4.70K 1/4W(3 5% TA52
R426 0RD4701Q609 4.70K 1/4W(3 5% TA52
R429 0RD1000Q609 100 1/4W(3 5% TA52
R430 0RD1000Q609 100 1/4W(3 5% TA52
R431 0RD4701Q609 4.70K 1/4W(3 5% TA52
R432 0RD1000Q609 100 1/4W(3 5% TA52
R433 0RD1000Q609 100 1/4W(3 5% TA52
R434 0RD1000Q609 100 1/4W(3 5% TA52
R438 0RD1001Q609 1K 1/4W(3 5% TA52
R439 0RD1001Q609 1K 1/4W(3 5% TA52
R444 0RD1002Q609 10K 1/4W(3 5% TA52
R445 0RD4702Q609 47K 1/4W(3 5% TA52
R446 0RD1002Q609 10K 1/4W(3 5% TA52
R447 0RD1001Q609 1K 1/4W(3 5% TA52
R448 0RD1801Q609 1.80K 1/4W(3 5% TA52
R501 0RD0102A609 10 OHM 1/2 W (7.0) 5% TA52
R508 0RD2202Q609 22K 1/4W(3 5% TA52
R515 0RD1502Q609 15K 1/4W(3 5% TA52
R597 0RD3902Q609 39K 1/4W(3 5% TA52
R598 0RD3601Q609 3.60K 1/4W(3 5% TA52
R599 0RD0202A609 20 OHM 1/2 W (7.0) 5% TA52
- 25 -
TRANSISTOR
RESISTORs
