- 25 -
DATE: 2003. 5. 9.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C201 0CN1040K949 0.1M 50V Z F TA52
C301 0CQ1021N419 1000P 100V J POLY NI TP
C302 0CE106CF638 10UF SHL,SD 16V M FM5 TP 5
C303 0CC5600K415 56P 50V J NP0 TP
C304 0CC5600K415 56P 50V J NP0 TP
C305 0CE476CF638 47UF SHL,SD 16V M FM5 TP 5
C306 0CZZTFT001M ECQB1H103JF3 MATSUSHITA 50V
C308 0CK1020K515 1000PF 50V K B TR
C309 0CK1040K945 0.1UF 50V Z F TR
C311 0CK1040K945 0.1UF 50V Z F TR
C312 0CK1040K945 0.1UF 50V Z F TR
C313 0CK1040K945 0.1UF 50V Z F TR
C314 0CC4700W405 47PF 500V J SL TP
C315 0CE476CF638 47UF SHL,SD 16V M FM5 TP 5
C317 0CK1040K945 0.1UF 50V Z F TR
C318 0CK1040K945 0.1UF 50V Z F TR
C319 0CK1040K945 0.1UF 50V Z F TR
C320 0CK10202515 1000PF D 2KV 10% TR B(Y5P)
C321 0CE225CK638 2.2UF SHL,SD 50V M FM5 TP 5
C323 0CE476CF638 47UF SHL,SD 16V M FM5 TP 5
C324 0CK1040K945 0.1UF 50V Z F TR
C325 181-288B MKT 100V 104JTR PHS26104
C326 0CC2200W415 22PF 500V J NP0 TR
C327 181-288B MKT 100V 104JTR PHS26104
C328 0CE226CN638 22UF SHL,SD 100V M FM5 TP 5
C329 181-288B MKT 100V 104JTR PHS26104
C330 181-288B MKT 100V 104JTR PHS26104
C331 181-288G MKT 100V 334JTR PHS26334
C332 181-288G MKT 100V 334JTR PHS26334
C333 181-288G MKT 100V 334JTR PHS26334
C334 181-288B MKT 100V 104JTR PHS26104
C335 181-288B MKT 100V 104JTR PHS26104
C339 0CK1520W515 1500P 500V K B TS
C340 181-288B MKT 100V 104JTR PHS26104
C341 0CK10202515 1000PF D 2KV 10% TR B(Y5P)
C344 181-288B MKT 100V 104JTR PHS26104
C346 0CK10302940 0.01M 2KV Z F S
C372 0CK1040K945 0.1UF 50V Z F TR
C401 0CK1040K945 0.1UF 50V Z F TR
C402 0CE476CF638 47UF SHL,SD 16V M FM5 TP 5
C403 0CK1040K945 0.1UF 50V Z F TR
C406 0CK1010K515 100PF 50V K B TR
C407 0CK1010K515 100PF 50V K B TR
C408 0CK1040K945 0.1UF 50V Z F TR
C410 0CK1010K515 100PF 50V K B TR
C412 0CK1040K945 0.1UF 50V Z F TR
C501 0CE106CF638 10UF SHL,SD 16V M FM5 TP 5
C599 0CE225CK638 2.2UF SHL,SD 50V M FM5 TP 5
C601 0CE477EH618 470UF KMG 25V M FL TP 5
C602 181-288B MKT 100V 104JTR PHS26104
C603 0CE476CK638 47UF SHL,SD 50V M FM5 TP 5
C604 0CZZTFT001V ECQB1H473JM3 473J 50V TP5.0
C605 0CK1020W515 1000P 500V K B TS
DATE: 2003. 5. 9.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C701 0CQ5621N419 5600P 100V J POLY NI TP
C702 0CZZTFT001M ECQB1H103JF3 MATSUSHITA 50V
C703 0CZZTFT001Z ECQB1H104JM3 104J 50V TP5.0
C704 0CQ8221N519 0.0082U 100V K POLY NI TP
C706 0CZZTFT001Z ECQB1H104JM3 104J 50V TP5.0
C707 0CZZTFT002B ECQV1H154JZ3 154J 50V TP5.0
C708 0CE227CH638 220UF SHL,SD 25V M FM5 TP 5
C709 0CZZTFT001P ECQB1H153JM3 153J 50V TP5.0
C711 0CQ5621N419 5600P 100V J POLY NI TP
C713 0CK2210K515 220P 50V K B TS
C714 0CE107CH638 100UF SHL,SD 25V M FM5 TP 5
C715 181-288N MKT 100V 103JTR PHS86103
C716 0CK2710K515 270P 50V K B TS
C717 0CZZTFT001R ECQB1H223JM3 223J 50V TP5.0
C718 0CZZTFT001V ECQB1H473JM3 473J 50V TP5.0
C719 0CZZTAB001F SHL-BP SYE / SWE 50V 3.3UF 2
C720 0CK27101515 270P 1KV K B TS
C722 181-303R 304J 31.0*21.0*13.0*20.0 250
C723 181-305C 154J 19.0*14.0*8.0*10.0 250V
C724 0CN1040K949 0.1M 50V Z F TA52
C725 0CK8210W515 820P 500V K B TS
C726 181-482F 274JF 18.0*17.0*10.0*7.5 250
C727 0CN1040K949 0.1M 50V Z F TA52
C728 0CQ5621N419 5600P 100V J POLY NI TP
C729 181-305W 604J 26.0*19.0*12.5*15.0 250
C730 0CN1040K949 0.1M 50V Z F TA52
C731 0CBZTBU004H 5600PF D 2.5KV H M/PP NI FM2
C732 181-288N MKT 100V 103JTR PHS86103
C733 0CBZTBU003H 362J 20.0*12.0*7.0*10.0 800V
C734 0CE226CK638 22UF SHL,SD 50V M FM5 TP 5
C737 0CK10102515 100PF D 2KV 10% B(Y5P) TR
C738 181-302L 682J 19.5*12.0*7.0*10.0 250V
C739 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C740 0CE227EL630 220UF KMG 63V M FM5 BULK
C741 0CZZTFT002B ECQV1H154JZ3 154J 50V TP5.0
C742 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C743 0CZZTFT002B ECQV1H154JZ3 154J 50V TP5.0
C744 0CZZTAB005A SMSHR SYE / SWE 160V 47UF 20
C745 0CK5610W515 560P 500V K B TS
C746 0CK3310W515 330P 500V K B TS
C747 0CK1040K945 0.1UF 50V Z F TR
C748 0CK1510W515 150PF 500V K B TR
C749 0CE105CQ638 1UF SHL,SD 200V M FM5 TP 5
C750 0CK1040K945 0.1UF 50V Z F TR
C751 181-288J MKT 100V 563JTR PHS26563
C752 0CQ4721N419 0.0047U 100V J POLY NI TP5
C753 0CK10301945 10000PF D 1KV Z F(Y5V) TR
C754 0CC4700W405 47PF 500V J SL TP
C756 0CK1010K515 100PF 50V K B TR
C767 0CK10301945 10000PF D 1KV Z F(Y5V) TR
C771 0CK10301945 10000PF D 1KV Z F(Y5V) TR
C774 0CZZTFT001Z ECQB1H104JM3 104J 50V TP5.0
C801 0CE105CK638 1UF SHL,SD 50V 20% FM5 TP 5
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
CAPACITORS
To Next Page
