LG StudioWorks E700B - Exploded View Parts Identification

EXPLODED VIEW PARTS LIST
- 24 -
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
A
B
Description
CABINET ASSEMBLY, EB770F(LG CDT) BRAND C062 PC+ABS,85964, S/WE700B (EB770G-EA)
CABINET ASSEMBLY, EB770F BRAND C062 AF320T,85964, S/WE700S (EB770G-NA)
CABINET ASSEMBLY, EB770F BRAND C062 320T,85964, E700S (EB770G-NA)
CABINET ASSEMBLY, EB770F BRAND C062 320T, FLATRON E700S (EB770G-NA)
CDT(CIRC), M41QEE903X 01NLGD FOR NORTHERN HEMISPHERE (EB770G-EA), (EB770G-NA ; )
CDT(CIRE), M41QEE903X 01RLGD LG-PHILIPS FOR EQUATORIAL
CDT(CIRC), M41QEE903X 01NLAD LG-PHILIPS FOR NORTHERN HEMISPHERE (EB770G-NA)
BACK COVER ASSEMBLY, EB770F C035 PC+ABS,85964,LG CORE (EB770G-EA)
BACK COVER ASSEMBLY, EB770F C035 AF320T,85964,LG CORE (EB770G-NA)
TILT SWIVEL ASSEMBLY, EB770F T057/B046 60HR,85964
SCREW ASSY PHP+5*25 (FZMW1)+GW18
COIL,DEGAUSSING, LX31 GET 0.4*120TS,1130MM,19 OHM,W/O EARTH
FBT (FLY BACK TRANSFORMER), 1054A,CB777G LG-PHILIPS 17"
SOCKET(CIRC),POWERSA-4S HUA JIE AC UNIVERSAL 3PIN BLACK
PWB(PCB) ASSEMBLY,SUB, EB770G CONTROL TOTAL BRAND CA-109 (EB770G-EA), (EB770G-NA)
PWB(PCB) ASSEMBLY,SUB, EB770G.KQIDML CONTROL TOTAL BRAND CA-109 (EB770G-NA; INDIA)
CABLE,D-SUB UL 2990-9C(7.5) AT 1560MM GLAY CB777G DM
METAL SHIELD BOTTOM(A-CKD)
HOLDER, PCB FIX , PC+ABS
BRACKET, EB770F SUPPORTER CDT
ADAPTER, SIGNAL, LIBERTY ENHANCE MAC 6-DIP (JAPAN ONLY)
ADAPTER,AC, KPR-24 KAWASAKI 125V 15A BLACK (JAPAN ONLY)
MAIN TOTAL ASSEMBLY, EB770G BRAND CA-109 (EB770G-EA)
MAIN TOTAL ASSEMBLY, EB770G.NT.DPM2 BRAND CA-109 (EB770G-NA)
MAIN TOTAL ASSEMBLY, EB770G.KQIDML BRAND CA-109 (EB770G-NA; INDIA)
MAIN TOTAL ASSEMBLY, EB770G NT MPR-II BRAND CA-109 (EB770G-NA ; )
PWB(PCB) ASSEMBLY,MAIN, EB770G KXLVET BRAND CA-109 TOTAL (EB770G-EA)
PWB(PCB) ASSEMBLY,MAIN, EB770G NT.DPM2 BRAND CA-109 TOTAL (EB770G-NA)
PWB(PCB) ASSEMBLY,MAIN, EB770G KQIDML BRAND CA-109 TOTAL (EB770G-NA; INDIA)
PWB(PCB) ASSEMBLY,MAIN, EB770G NT MPR-II BRAND CA-109 TOTAL (EB770G-NA; )
Part No.
3091TKC067A
3091TKC067M
3091TKC067P
3091TKC067L
2423GC4E95A
2423GC4E96A
2423GC4E97A
3809TKC035J
3809TKC035K
3043TKK081A
339-002J
6140TC3004E
6174T11003E
6620TKB002B
6871TST282C
6871TST282D
6850TA9004A
4950TKS169A
4930TKK031C
4810TKK171B
6634TFZ002A
381-240A
3313T17251C
3313T17251E
3313T17251F
3313T17251G
6871TMT284C
6871TMT284D
6871TMT284E
6871TMT284F
