MODEL: (EB770G-EA), (EB770G-NA) DATE: 2002. 1. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
ZD301 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD302 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD401 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD404 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD405 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD406 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD407 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD410 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD411 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD701 0DZ110009CF GDZJ11B TP GRANDE DO34 0.5W 11
ZD702 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD705 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW 5
ZD901 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW 5
ZD902 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW 5
IC301 0IPRPMJ008A MTV038N-15EG MYSON 16P DIP ST
IC302 0IPRPNS003A LM1269NA NATIONAL SEMICONDUCTO
IC303 0IPRPNS009A LM2469TA NATIONAL SEMICONDUCTO
IC304 0IPRPNS005A LM2480NA NATIONAL SEMICONDUCTO
IC401 0IZZTSZ169A SS 42PIN ST G-CHASSIS 6KEY CA-
IC402 0ISG240860A M24C08-BN6 8DIP BK 8K SERIAL I
IC402 0ISG240860A M24C08-BN6 8DIP BK 8K SERIAL I
IC403 0IKE704200H KIA7042AP TO-92 TP 4.2 VOLT.
IC601 0IPH486600C TDA4866J 9P ST VERTICAL OUTPUT
IC701 0IPRPPH008A TDA4857PS(V2) PHILIPS SDIP32 S
IC901 0IPMGSK004A STR-G8644D(LF1140) SANKEN 5P S
L301 0LA0270K119 0.27UH K 2.3*3.4 TP
L302 0LA0270K119 0.27UH K 2.3*3.4 TP
L303 0LA0270K119 0.27UH K 2.3*3.4 TP
L304 0LA1000K119 100UH K 2.3*3.4 TP
L311 0LA0820K119 0.82UH K 2.3*3.4 TP
L312 0LA0820K119 0.82UH K 2.3*3.4 TP
L313 0LA0820K119 0.82UH K 2.3*3.4 TP
L702 6140TBZ025C DR14*20 150UH 0.12*25MM 51T H-
L703 6140TYZ010F LX31 GET DR14*15-C5.2,19.5T,6.
L705 6140TBZ026C DR15*18-C9.8 100UH 0.1*30MM 40
L901 6200TLS004B SQE2424 15MH 0.55MM 70T CB775C
FB201 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB301 6210TCE003F BRD3580B BO SUNG 3580MM RADIAL
FB302 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB303 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB304 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB305 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB308 6210TCE003G BRS3550B BO SUNG 3550MM RADIAL
FB309 971-0016 TIN HDC 0.60H
FB310 6210TCE003A BRD3510B BO SUNG 3510MM RADIAL
FB311 6210TCZ001J BAS3550T0(125-022J) BO SUNG RH
FB312 6210TCZ001J BAS3550T0(125-022J) BO SUNG RH
FB313 6210TCZ001J BAS3550T0(125-022J) BO SUNG RH
FB401 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB402 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB403 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
FB701 6210TCE003L BAS3580T BO SUNG 3580MM AXIAL5
FB703 6210TCE003B BRS3580B BO SUNG 3580MM RADIAL
MODEL: (EB770G-EA), (EB770G-NA) DATE: 2002. 1. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
FB705 6210TCE003L BAS3580T BO SUNG 3580MM AXIAL5
FB901 6210TCE003P BRS2550B BO SUNG 2550MM RADIAL
FB904 6210TCE003K BAS3550T BO SUNG 3550MM AXIAL5
FB913 6210TCE003P BRS2550B BO SUNG 2550MM RADIAL
FB921 6210TCE003A BRD3510B BO SUNG 3510MM RADIAL
FB922 6210TCE003H BAS3510T BO SUNG 3510MM AXIAL5
FB951 6210TCE003J BAS2550T BO SUNG 2550MM AXIAL5
Q501 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q502 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q503 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q701 0TR200009AB KTC200-Y TP KEC TO92 NPN
Q706 0TR580301AA FAIRCHILD KSC5803(TBTU) ST TO-
Q707 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q708 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q709 0TR141300AB KTD1413 BK KEC TO220I S NPN
Q710 0TR440009CA KSP44 TP SAMSUNG
Q711 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5A
Q712 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5A
Q713 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5A
Q714 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q715 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q716 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q719 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5A
Q720 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q722 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q723 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q799 0TR920009AB KSP92 TP SAMSUNG TO92 HIGH VOL
Q903 0TRFC10003A FAIRCHILD KSD882Y-S ST TO126 4
Q941 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q942 0TR928009AB KSA928A-Y TP SAMSUNG TO92L PNP
Q951 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q952 0TR928009AB KSA928A-Y TP SAMSUNG TO92L PNP
Q953 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
R201 0RD1001Q609 1K 1/4W(3 5% TA52
R202 0RD0912Q609 91 OHM 1/4 W (3.4) 5% TA52
R203 0RD2200Q609 220 1/4W(3 5% TA52
R204 0RD4300Q609 430 OHM 1/4 W(3.4) 5.00% TA52
R205 0RD1001Q609 1K 1/4W(3 5% TA52
R206 0RD0912Q609 91 OHM 1/4 W (3.4) 5% TA52
R207 0RD4300Q609 430 OHM 1/4 W(3.4) 5.00% TA52
R208 0RD2200Q609 220 1/4W(3 5% TA52
R209 0RD9100Q609 910 1/4W(3 5% TA52
R210 0RD2200Q609 220 1/4W(3 5% TA52
R211 0RD2200Q609 220 1/4W(3 5% TA52
R301 0RD0752Q609 75 1/4W(3 5% TA52
R302 0RD0752Q609 75 1/4W(3 5% TA52
R303 0RD0752Q609 75 1/4W(3 5% TA52
R304 0RD3301Q609 3.30K 1/4W(3 5% TA52
R305 0RD5601Q609 5.60K 1/4W(3 5% TA52
R306 0RD5601Q609 5.60K 1/4W(3 5% TA52
R307 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R310 0RD1000Q609 100 1/4W(3 5% TA52
R312 0RD1001Q609 1K 1/4W(3 5% TA52
- 27 -
COILs & COREs
ICs
RESISTORs
TRANSISTORs
To Next Page
