78
Are the main PCB connector (BL12) and thermistor connector (WH2) at the top
of the condenser properly assembled?
Is the COMP_THERMISTOR properly assembled?
(deviation, etc.)
Replace the thermistor.
Is the thermistor connector (WH2) properly connected?
Is the coil of LEV properly assembled?
Connect the connector.
Assemble the thermistor.
(Insert it to the pipe.)
Connect the connector.
Assemble the coil properly.
12-10. TE1
12-11. T E2
NO
NO
NO
NO
YES
YES
YES
YES
