79
Is the LEV connector (WH5) properly assembled?
Is the comp connector (WH3) properly assembled?
Are the main PCB connectors (RD3, BL12, NA5) properly connected?
Do you feel the vibration of comp 1 minute after starting the Drying cycle?
Check the leakage of refrigerant and perform repair.
Connect the connector.
Connect the connector.
Connect the connector.
Replace comp and perform repair.
NO
NO
NO
NO
YES
YES
YES
YES
To Next Page
