LG SV-iS5 User Manual

modbus-rtu iS5 manual.doc
8
Address NO. Description Default Maximum Minimum Unit
5105 DRV#05
Step freq - 1 1000 MaxFreq startFreq 0.01Hz
5106 DRV#06
Step freq - 2 2000 MaxFreq startFreq 0.01Hz
5107 DRV#07
Step freq - 3 3000 MaxFreq startFreq 0.01Hz
5108 DRV#08
Current - - - 0.1A
5109 DRV#09
Speed - - - 1rpm
510A DRV#10 DC Link Voltage - - V
< FU1 Group >
Address NO. Description Default Maximum Minimum Unit
5203 FU1 #03 Run prohibit 0 2 0
5205 FU1 #05 Acc. pattern 0 4 0
5206 FU1 #06 Dec. pattern 0 4 0
5207 FU1 #07 Stop mode 0 2 0
5208 FU1 #08 DcBr freq. 500 6000 startFreq 0.01Hz
5209 FU1 #09 DcBlk time 10 6000 0 0.01sec
520A FU1 #10 DcBr value 50 200 0 %
520B FU1 #11 DcBr time 10 600 0 0.1sec
520C FU1 #12 DcSt value 50 200 0 %
520D FU1 #13 DcSt time 0 600 0 0.1sec
5214 FU1 #20 Max freq. 6000 40000 4000 0.01Hz
5215 FU1 #21 Base freq. 6000 maxFreq 3000 0.01Hz
5216 FU1 #22 Start freq. 50 6000 1 0.01Hz
5217 FU1 #23 Freq limit 0 1 0
5218 FU1 #24 F-limit Lo. 50 highFreq startFreq 0.01Hz
5219 FU1 #25 F-limit Hi. 6000 maxFreq lowFreq 0.01Hz
521A FU1 #26 Torque boost 0 1 0
521B FU1 #27 Fwd boost 20 150 0 0.1%
521C FU1 #28 Rev boost 20 150 0 0.1%
521D FU1 #29 V/F pattern 0 2 0
521E FU1 #30 User freq. 1 1500 maxFreq 0 0.01Hz
521F FU1 #31 User volt. 1 25 100 0 %
5220 FU1 #32 User freq. 2 3000 maxFreq 0 0.01Hz
5221 FU1 #33 User volt. 2 50 100 0 %
5222 FU1 #34 User freq. 3 4500 maxFreq 0 0.01Hz
5223 FU1 #35 User volt. 3 75 100 0 %
5224 FU1 #36 User freq. 4 6000 maxFreq 0 0.01Hz
5225 FU1 #37 User volt. 4 100 100 0 %
5226 FU1 #38 Volt control 1000 1100 400 0.1%
