LG TD-C70212E User Manual

Installation Instructions
7
I
nstallation Instructions
GROUNDING INSTRUCTION
This appliance must be grounded. In the event of
malfunction or breakdown, grounding will reduce
the risk of electric shock by providing a path of
least resistance for the electric current.
This appliance is equipped with a cord having an
equipment grounding conductor and a grounding
plug. The plug must be plugged into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
Condensate Drain
The dryer can drain water without delivering to
water container. Water is directly pumped out of
the dryer.
Stacking Kit
In order to stack this dryer on a LG washing
machine, LG stacking kit is needed.
Washer top plate size
Shape
600 mm
550 mm
In order to stack this dryer on LG Washing
machine, you must purchase the LG stacking
kit that is fitted by LG washing machine top
plate size.
•You must use stacking kit according to your
washer Top plate size
550
Additional Grounding Procedure
Some local codes may require a separate ground.
In such cases, the required accessory ground
wire, clamp and screw must be purchased
separately.
600

LG TD-C70212E Specifications

General

Display type	LED
Loading type	Front-load
Product color	White
Reversible doors	Yes
Appliance placement	Freestanding
Cycle time	119 min
Drum capacity	7 kg
Number of drying programs	10
Delay start (max)	19 h
Current	16 A
Connected load	2900 W
AC input voltage	220 - 230 V
AC input frequency	50 Hz
Energy consumption	3.92 kWh

Weight and Dimensions

Depth	585 mm
Width	595 mm
Height	850 mm
Weight	40000 g
