LG TD-C70212E User Manual

Caring for your dryer
18
Reverse the door
The door can be reversed to fit to your own
installation conditions. From the factory, the door
hinge is located on the right side.
1. Unscrew the bottom hinge of the door first
and top hinge. And then place on the blanket
to prevent scratches.
2. Remove the
door lock cover.
3. Remove the
door lock and
replace where
door lock cover
is located.
4. Detach both
hinge point
covers.
5. Unscrew two
door hinges.
6. Replace both
hinge point
covers where
door hinge is
located.
7. Replace the
door catch to
the reverse
location.
8. Screw the door
hinges.
CAUTION
1. This work may cause the injury of your
hands so you must be careful to handle
some sharp devices like tork screwdriver or
slotted screwdriver.
2. When the door is revered, the hand sticker
on the door also must be replaced.
Do not use a machine screwdriver.
aring for your dryer
C

LG TD-C70212E Specifications

General

Display type	LED
Loading type	Front-load
Product color	White
Reversible doors	Yes
Appliance placement	Freestanding
Cycle time	119 min
Drum capacity	7 kg
Number of drying programs	10
Delay start (max)	19 h
Current	16 A
Connected load	2900 W
AC input voltage	220 - 230 V
AC input frequency	50 Hz
Energy consumption	3.92 kWh

Weight and Dimensions

Depth	585 mm
Width	595 mm
Height	850 mm
Weight	40000 g
