Note :
1. Capacities and power inputs are based on the following conditions:
* : Cooling conditions - Indoor Water Temperature 23°C/18°C; Outdoor Air Temperature 35°CDB/24°CWB
Heating conditions - Indoor Water Temperature 30°C/35°C; Outdoor Air Temperature 7°CDB/6°CWB
Standard piping length 7.5m
2. Wiring cable size must comply with the applicable local and national code.
3. The specification may be subject to change without prior notice for purpose of improvement.
4. ** Indoor unit Rated water flow rate.
Outdoor Units AHUW126A3 AHUW146A3 AHUW166A3
Combination Indoor Units AHNW16606B0 AHNW16606B0 AHNW16606B0
Power Supply Ø / V / Hz 1 / 220-240 / 50 1 / 220-240 / 50 1 / 220-240 / 50
Maximum Running Current
Cooling A 25 25 25
Heating A 25 25 25
Wiring Connections
For Power Supply
(Included Earth)
Number of
wires
3 3 3
* Capacity
Cooling(Under floor) kW 10.4 11.0 12.0
Heating(Under floor) kW 12.0 14.0 16.0
* Power Input
Cooling(Under floor) kW 3.30 3.53 4.00
Heating(Under floor) kW 2.78 3.43 4.18
* EER Cooling(Under floor) W/W 3.15 3.12 3.00
* COP Heating(Under floor) W/W 4.32 4.08 3.83
Operation Range (Min.~Max.)
Outdoor Temperature
Cooling °C 5 ~ 48 5 ~ 48 5 ~ 48
Heating °C -20 ~ 30 -20 ~ 30 -20 ~ 30
Compressor
Type - Hermetic Motor Hermetic Motor Hermetic Motor
Model - GPT442MAA GPT442MAA GPT442MAA
Quantity EA 1 1 1
Displacement cm
3
/Rev. 44.2 44.2 44.2
Capacity kW 13.92 13.92 13.92
Compressor Motor
Type - Brushless Brushless Brushless
Quantity EA 1 1 1
Rated Output W 4,000 4,000 4,000
Refrigerant
Type - R410A R410A R410A
Charge g 2,300 2,300 2,300
Control - EEV EEV EEV
Refrigerant Oil
Type - FVC68D FVC68D FVC68D
Charged Volume cc 1,300 1,300 1,300
Heat Exchanger
Quantity EA 2 2 2
Rows EA 2 2 2
Columns EA 32 32 32
FPI Fins/inch 14 14 14
Fan
Type - Propeller Propeller Propeller
Quantity EA 2 2 2
Air Flow Rate CMM(l/s) 55 55 55
Fan Motor
Model - BLDC BLDC BLDC
Quantity EA 2 2 2
Output W 124 124 124
Sound Power Level Heating dB(A) 66 66 66
Liquid Piping Connection
Type - Flare Flare Flare
Outer Diameter mm(inch) Ø 9.52 (3/8) Ø 9.52 (3/8) Ø 9.52 (3/8)
Gas Piping Connection
Type - Flare Flare Flare
Outer Diameter mm(inch) Ø 15.88 (5/8) Ø 15.88 (5/8) Ø 15.88 (5/8)
Piping Length
(Outdoor Unit ~ Indoor Unit)
Minimum m 3 3 3
Standard m 7.5 7.5 7.5
Maximum m 50 50 50
Height Difference
(Outdoor Unit ~ Indoor Unit)
Maximum m 30 30 30
Additional Refrigerant Charge g/m 40 40 40
Dimensions
Unit(W x H x D) mm 950 x 1,380 x 330 950 x 1,380 x 330 950 x 1,380 x 330
Packed Unit(W x H x D) mm 1,140 x 1,462 x 461 1,140 x 1,462 x 461 1,140 x 1,462 x 461
Weight
Unit kg 94 94 94
Packed Unit kg 107 107 107
**Rated water flow rate LPM 34 40 46
