Connecting the cable between indoor unit and outdoor unit
The power cord connected to the outdoor unit should be complied with the following specifications
(ETL recognized and CSA certified).
The power connecting cable connected to the indoor and outdoor unit should be complied with
the following specifications.
GN/YL
20mm
GN/YL
20mm
GN/YL
20mm
0.75
Cable Type(B) H07RN-F
NORMAL CROSS
-SECTIONAL AREA
Grade
(mm
2
)
T2UH182FAA T2UH242FAA
2.5 2.5
Cable Type(B) H07RN-F H07RN-F
NORMAL CROSS
-SECTIONAL AREA
Grade
(mm
2
)
T2UH182FAA T2UH242FAA
48 Multi Air Conditioner
