8 Multi Air Conditioner
Product Specifications
Note :
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB
- Outdoor Temperature 35°C(95°F) DB / 23.9°C(75°F) WB
Piping Length - Interconnecting Piping Length 7.5m
- Level Difference of Zero.
2. Due to our policy of innovation some specifications may be changed without notification.
3. At least two indoor units should be connected.
Outdoor Unit
Unit T2UH182FAA T2UH242FAA
W 3077/ 3077 3517 / 3517
Btu/hr 10500 / 10500 12000 / 12000
W 3077/ 3077 3517 / 3517
Btu/hr 10500 / 10500 12000 / 12000
W 5275 / 5275 7034
Btu/hr 18,000 / 18,000 24,000
Power input
(Cooling/heating)
A+B W 1850/1650 2380/2420
Running current
(Cooling/heating)
A+B A 8.6/ 7.6 11/11.3
f,V,Hz 1,220,60 1,220,60
No. * mm
2
3*2.5 3*2.5
No. * mm
2
4*0.75 4*0.75
W/W 2.85 2.96
Btu/hr W 9.7 10.1
W/W 3.20 2.91
Btu/hr W 10.9 9.9
Capillary Capillary
g(oz), type 1050, R22 A: 650 /B: 650 R22
Dimensions (W*H*D)
Outdoor unit mm 801*555*262 870*655*320
Packing dimensions (W*H*D)
Outdoor unit mm 960*610*384 1002*700*422
kg (lbs) 50 (110) 63 (139)
Rotary Rotary
1 2
QJ278KDF QK185KBK
LG LG
SUNISO 4GSI SUNISO 4GSI
MOTOR TYPE PSC PSC
Oil charge cc 410 350
Tube size (OD) inch (mm) 0.276 (7.0) 0.276 (7.0)
18 18
2R 24C 2R 28C
Model YGK25-6A-9 KFD-60K11
No. of poles 6 6
CMM (CFM) 49 (1398) 40 (1142)
Propeller Propeller
No. used / dia.
EA / inch (mm)
1 / 18.1(460) 1 / 18.1(460)
Side discharge Side discharge
RPM ±30 1020 880
dB +3(dB+1) 54(56) 54(56)
Liquid A inch (mm) 1/4 (6.35) 1/4 (6.35)
Gas A inch (mm) 3/8 (9.52) 1/2 (12.7)
Liquid B inch (mm) 1/4 (6.35) 1/4 (6.35)
Gas B inch (mm) 3/8 (9.52) 1/2 (12.7)
Max piping length total
m 30 30
Std. Piping length m 7.5 7.5
m 15 / 7.5 15 / 7.5
Stuff Quantity (Set) 20FT/40FT/40FT(H) 80/168/192 65/138/156
Power supply
Power supply cable
Connecting cable
Item
Capacity
(Cooling/heating)
A (SY 9K)
B (SY 9K )
A+B (9K+9K)
EER
cooling
COP
heating
Refrigerant control
Refrigerant charge
Net weight
Compressor
Type
Quantity
Model name
Maker
Oil type
Outdoor coil
FPI
No. of rows & columns
Noise level +3
SVC valves
Max. piping length per each room / elevation
Outdoor Motor
Air circulation
Outdoor fan
Type
Dischage
