MULTI F MAX OUTDOOR UNIT
'LPHQVLRQV
Supporter
4-holes for anchor bolts
No.
1
2
3
4
Part Name
Air discharge grille
Gas pipe connection
Liquid pipe connection
Power & transmission connection
4
19-9/32
21-1/20
53-3/8
54-11/32
15-3/4
6-1/2 6-1/2
24-13/32
14-3/16
13
6-5/8
14-1/20
37-13/32
Unit: inch
Center of Gravity
Figure 23: LMU480HV, LMU540HV, and LMU600HV External Dimensions.
