25
ENGLISH
MAKING CONNECTIONS
Satellite dish connection
(Only satellite models)
IN
13 / 18 V
700mA Max LNB IN
Satellite
IN
13 / 18 V
LNB IN
Satellite
700mA Max
(*Not Provided)
Connect the TV to a satellite dish to a satellite
socket with a satellite RF cable (75 ).
HDMI connection
HDMI
/DVI IN
(4K@60Hz)
2 (ARC)
1 (HDCP2.2)
(4K@60Hz)/
DVI IN
3 (MHL)
DVD / Blu-Ray / HD Cable Box
/ HD STB / PC
(*Not Provided)
Transmits the digital video and audio signals
from an external device to the TV. Connect the
external device and the TV with the HDMI cable
as shown.
Choose any HDMI input port to connect. It does
not matter which port you use.
To Next Page
