37
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Wireless module (LGSBW41) specification
Wireless LAN Bluetooth
Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 3.0
Frequency Range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz (for Non EU)
Frequency Range 2400 to 2483.5 MHz
Output Power
(Max.)
802.11a: 13 dBm
802.11b: 15 dBm
802.11g: 14 dBm
802.11n - 2.4GHz: 16 dBm
802.11n - 5GHz: 16 dBm
Output Power
(Max.)
10 dBm or lower
y
Because band channel used by the country could be different, the user can not change or adjust
the operating frequency and this product is set for the regional frequency table.
y
This device should be installed and operated with minimum distance 20 cm between the
device and your body. And this phrase is for the general statement for consideration of user
environment.
