LG W2242S User Manual

A9
On Screen Display (OSD) Control Adjustment
Screen Adjustment
Making adjustments to the image size, position and operating parameters of
the display is quick and easy with the On Screen Display Control system.
A short example is given below to familiarize you with the use of the controls.
The following section is an outline of the available adjustments and selections
you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the MENU Button, then the main menu of the OSD appears.
To access a control, use the or Buttons. When the icon you want
becomes highlighted, press the AUTO/SET Button.
Use the / Buttons to adjust the image to the desired level. Use the
AUTO/SET Button to select other sub-menu items.
Push the MENU Button once to return to the main menu to select another
function. Push the MENU Button twice to exit from the OSD.
NOTE
Allow the display to stabilize for at least 30 minutes before making image adjustments.
AUTO/SET
MENU MENU

LG W2242S Specifications

General

Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewing angle, vertical	170 °
Contrast ratio (dynamic)	8000:1
Contrast ratio (typical)	700:1
Display brightness (typical)	300 cd/m²
Box depth (imperial)	5 \
Box width (imperial)	22.59836 \
Box height (imperial)	16.02 \
Safety	UL(cUL), TUV-GS, SEMKO
Product color	Silver
Market positioning	-
Power consumption (standby)	1 W
Power consumption (typical)	40 W
Manual	Yes
DVI-I ports quantity	0
Built-in camera	2020-02-10T09:07:15.000Z

Weight and Dimensions

Depth (with stand)	209.4 mm
Width (with stand)	515.7 mm
Height (with stand)	418 mm
Weight (with stand)	4650 g
Depth (without stand)	63.06 mm
Height (without stand)	344.6 mm
Weight (without stand)	4450 g
