LG W2443T-PF User Manual

7
Connecting the Display W2443S
NOTE
‘ Self Image Setting Function’? This function provides the user with optimal display
settings.When the user connects the monitor for the first time, this function automatically adjusts
the display to optimal settings for individual input signals.
‘AUTO/SET’ Function? When you encounter problems such as blurry screen, blurred letters,
screen flicker or tilted screen while using the device or after changing screen resolution, press
the AUTO/SET function button to improve resolution.
A
Connect D-sub(Analog signal) Cable
1. Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
2. Connect signal input cable and power cord in order, then tighten the screw
of the signal cable.
Connecting with the PC
1
2
PC
A
Wall-outlet type
Mac adapter : For Apple Macintosh use, a
separate plug adapter is needed to change the
15 pin high density (3 row) D-sub VGA
connector on the supplied cable to a 15 pin 2
row connector.
When using a D-Sub signal input cable connector for
Macintosh
Varies according to model.
3. Press the power button on the front panel to turn the power on. When monitor power is
turned on, the 'Self Image Setting Function' is executed automatically.
Power Button
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display may differ from the view as shown.

LG W2443T-PF Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:9
Response time	2 ms
Display diagonal	24 \
Viewing angle, vertical	160 °
Contrast ratio (typical)	-
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
HDCP	Yes
USB Type-A downstream ports quantity	0
Product color	Black
Quick start guide	2020-02-10T09:07:14.000Z

Weight and Dimensions

Depth (with stand)	242 mm
Width (with stand)	573 mm
Height (with stand)	462 mm
Weight (with stand)	5360 g
Depth (without stand)	0 mm
Weight (without stand)	- g
