LG W2443T-PF User Manual

10
On Screen Display (OSD) Control Adjustment
Screen Adjustment
Making adjustments to the image size, position and operating
parameters of the display is quick and easy with the On Screen
Display Control system.
A short example is given below to familiarize you with the use of the
controls. The following section is an outline of the available
adjustments and selections you can make using the OSD.
Pops up the
menu screen
To make adjustments in the On Screen Display, follow these steps:
Move where
you want to
adjust
Select a
menu icon
Adjust the
status
Exit from the
menu screen.
Press the MENU Button, then the main menu of the OSD appears.
To access a control, use the or Buttons. When the icon you want
becomes highlighted, press the AUTO/SET Button.
Use the / Buttons to adjust the image to the desired level.
Use the AUTO/SET Button to select other sub-menu items.
Press the MENU Button once to return to the main menu to select another
function. Press the MENU Button twice to exit from the OSD.
1
2
3
4

LG W2443T-PF Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:9
Response time	2 ms
Display diagonal	24 \
Viewing angle, vertical	160 °
Contrast ratio (typical)	-
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
HDCP	Yes
USB Type-A downstream ports quantity	0
Product color	Black
Quick start guide	2020-02-10T09:07:14.000Z

Weight and Dimensions

Depth (with stand)	242 mm
Width (with stand)	573 mm
Height (with stand)	462 mm
Weight (with stand)	5360 g
Depth (without stand)	0 mm
Weight (without stand)	- g
