LG WT7100CW Technical Manual

Part number change Main harness and Cooktop harness
Applicable for Serial Number : 905MM ~
1. Change assembly connection
Cooktop and main harness connections change
Page 1
Applicable for models
USA : LRE3061ST, LRE3061BD
Bulletin Type : SVC Notice Parts Others
Applicable only with symptoms with every repair
Symptoms
Unit shutdown, cooktop not working, oven not
working, etc.
Picture N/A
Cause Main harness and cooktop harness change

Before After
1 connector
2connectors
Service Bulletin
Product : Oven
Bulletin # : CVZ202000016-01
Release Date : 20.02.17


LG WT7100CW Specifications

General

Style	top load
Color	white
Washer Capacity	4.5 cubic feet
Max Spin Speed	950 revolutions per minute
Spin Speeds	3
Number of Cycles	8
Cycle Selections	normal, heavy duty, deep wash, waterproof, bedding, delicates, speed wash, tub clean
Options	soak, extra rinse, add garments, delay wash, control lock, water plus, coldwash, rinse+spin, spin only, tub clean, normal, heavy duty, deep wash, waterproof, bedding, delicates, speed wash, tub clean
Temperature Settings	3
Temperature Selections	hot, warm, cold
Soil Levels	3
Internal Heater	no
Control Panel	dial, touchpad
Delay Start / End	yes
Child Lock	yes
Cycle Signal	yes
Interior Light	no
Steam	no
Dispenser	single load
Smart Home	no
Annual Energy Consumption	220 kilowatt hours
Voltage	120 volts
Current	5 amperes

Weight and Dimensions

Depth	28 3/8 inches
Height	44 1/2 inches
Width	27 inches
Net Weight	134.5 pounds
