14
1 - GENERAL FEATURES
1.6 INTENDED USE – TECHNICAL AND OPERATIONAL FEATURES
SPIN1 is a yarn accumulator featuring separate coils suitable for all types of
knitting machines or textile machines requiring constant tension yarn feed-in.
Operational Features:
• Quick reaction to machine speed changes without causing tension peaks
on the yarn
• Quick reaction to set tension changes.
• Yarn tension adjustment from 0.5g to 100g.
• Maximum torque available at low speeds, too
• Special concern for reduction of energy consumption
• Yarn absorption measurement
• Easy installation and use
• RS485 and CAN BUS serial communication option
• Connections: via flat cable or traditional cable
• Ceramic tension sensor: guarantees accuracy, precision and quick response
Technical Specifications:
• Power supply voltage data: V = From 24VDC ± 10% to 60VDC ± 10%
(min 21,6 VDC - max 66 VDC)
• Average power in normal operation: 5W-15W (much relying on the type
of work process
• Peak power: 70W
• Automatic speed adjustment up to a maximum value of 1400 m/min.
• Coil separation feature from 0 to 2mm.
• A-weighted sound pressure level, at maximum speed, < than 70dB (A)
• Operation and storage conditions: Room temperature: +10 to +40 °C
• Max. humidity: 80%
