3 - START-UP AND THREADING
3.1 OFFSET
Once installed on the machine, connected to the power supply box and fed
with current, the accumulator appears to be ON.
WARNING: Before performing the OFFSET calibration, ensure
the accumulator is at a steady temperature. We suggest you go
through the cell reset procedure 15 minutes after power on.
WARNING: during the OFFSET calibration, the yarn shall never
touch the load cell. If yarn is found on the accumulator, hold the
X button pressed until the display unit shows the message
"WAIT: Yarn Winding". At this point, you can remove the yarn.
Calibrate the load cell ’OFFSET as detailed below:
Ensure the yarn never comes
into contact with the cell
