Specifications
Parameters of SR1323D (S13230NDCH20) Whole Machine
Performance Parameters of Whole Machine
Item
Parameters
Item
Parameters
Rated load (kg)
910
Ascending/descending
speed (s)
55/55
Recommended load capacity of
extension deck (kg)
230
Minimum turning radius
(outer wheel) (m)
5.33
Maximum number of workers
7
Maximum allowable angle
of operation (front and rear)
3°
Maximum working height (m)
15
Maximum allowable angle
of operation (left and right)
2°
Maximum platform height (m)
13
Maximum leveling angle of
outrigger (from front to rear)
7°
Extension dimension of front
platform (m)
1.45
Maximum leveling angle of
outrigger (from left to right)
12°
Extension dimension of rear
platform
1.14
Theoretical climbing ability
(mm)
40%
Running speed of machine
(folding state) (km/h)
6.1
Running height (m)
8.5
Running speed of machine (rising
state) (km/h)
1.1
Main Dimensions
Item
Parameters
Item
Parameters
Length of whole machine -
platform retraction (m)
4.9
Extension length - double
extension length (m)
6.58
Width of whole machine (m)
2.3
Wheel base (front/rear) (mm)
2,850
Height of whole machine -
unfolded guard railing (m)
2.96
Thread (mm)
1,993
Height of whole machine -
folded guard railing (m)
2.28
Ground clearance (folding state)
(m)
0.23
Dimension of main platform
(length × width) (m)
3.98×1.83
Tire specification (diameter ×
width)
835×290
Extension length - single
extension length (m)
5.44
Weight of whole machine (kg)
7275
Main Dimensions-7.2m platform (If equipped)
Item
Parameters
Item
Parameters
Length of whole machine -
platform retraction (m)
4.9
Extension length - double
extension length (m)
7.21
Width of whole machine (m)
2.3
Wheel base (front/rear) (mm)
2,850
Height of whole machine -
unfolded guard railing (m)
3.18
Thread (mm)
1,993
Height of whole machine -
2.5
Ground clearance (folding state)
0.23
