LGMG SR1018D - Page 64

Elevating Work Platform Operation Manual
57
5.1.2 Ground Control Station(Second generation)-SR1023D/SR1323D
/SR1623D
No.
Name
Operation function description
1
Timer
The timer displays hours that the machine has
been running.
2
Startup button of engine
Press this button to start up the engine.
3
Gasoline/LPG model: LPG operating
button with indicator
Press this button to select LPG.
4
Idling selection button of engine with
indicator
Press this button to select the idling setting of
engine. The indicator is on, indicating that the
middle and high idling has been selected. The
indicator is off, indicating that the middle and low
idling has been selected.
5
LCD display
6
Glow plug button
Press this button to activate the glow plug.
7
Lift button of platform
Press this button to lift the platform.
8
Enabling button with lift function
Press this button to activate the lift function.
9
Enabling button with standby auxiliary
Press this button to activate the emergency
