Lian-Li O11 DYNAMIC EVO XL User Manual

Graphics card installation
/ Installation de la carte graphique / Grafikkarteninstallation / 顯⽰卡安裝
Instalación de tarjeta gráfica / グラフィックカードの取り付け
Make sure the pole holds the GPU/
/定位凸柱要確實撐住顯卡
Assurez-vous que le poteau tient le
GPU
Remove the pillar
/ Column removal method / ⽴柱卸除⽅式
Methode zum Entfernen von Säulen /
Método de eliminación de columnas /
カラムの取り外し⽅法
Mak e s ur e t o fi x th e p il la r for
tra ns po rt ing/
/如需運送，務必將⽴柱鎖上
Ass ur ez -v ous de fix er le p il ie r
pou r l e t ra ns por t
- 9 -
推開拿出空⽚/
Pousser pour libérer le support
Push to release bracket/
Push/推/
Pousser
７
Gently hold the GPU
horizontally to close
the clamp smoothly/
把顯卡撐⾄⽔平位置/
Tenez doucement le
GPU horizontalement
pour fermer la pince
en douceur

Lian-Li O11 DYNAMIC EVO XL Specifications

General

Case Type	Full Tower
Motherboard Compatibility	E-ATX, ATX, Micro-ATX, Mini-ITX
Expansion Slots	8
Color	Black, White
Material	Steel, Tempered Glass, Aluminum
Drive Bays	3 x 3.5"
Front I/O	1x USB 3.1 Type-C, 2x USB 3.0, HD Audio
Fan Support	Rear: 1 x 120mm
Radiator Support	Top: Up to 360mm, Bottom: Up to 360mm, Side: Up to 360mm, Rear: 1 x 120mm
PSU Support	ATX (Up to 220mm)
GPU Clearance	460mm
CPU Cooler Clearance	167mm
