SPECIFICATIONS
MODEL NUMBER GXT1500RT-230 GXT2000RT-230 GXT3000RT-230
MODEL RATING VA/W 1500 / 1050 2000 / 1400 3000 / 2100
DIMENSIONS: mm (in)
Unit
W x D x H
177 x 522 x 430
(7.0 x 19.3 x 16.9)
177 x 522 x 430
(7.0 x 19.3 x 16.9)
177 x 522 x 430
(7.0 x 19.3 x 16.9)
Shipping
W x D x H
340 x 660 x 565
(13.38 x 26.0 x 22.25)
340 x 660 x 565
(13.38 x 26.0 x 22.25)
340 x 660 x 565
(13.38 x 26.0 x 22.25)
WEIGHT: kg (lbs)
Unit 27.7 (60.9) 36.8 (80.9) 39.0 (85.9)
Shipping 30.9 (68.0) 40.0 (88.0) 42.3 (93.0)
INPUT AC PARAMETERS
Voltage Range (typical) 230 VAC nominal; variable based upon output load
100% - 90% Loading 184-187 VAC to 273-276 VAC
90% - 70% Loading 160-163 VAC to 273-276 VAC
70% - 30% Loading 140-143 VAC to 273-276 VAC
30% - 0% Loading 120-122 VAC to 273-276 VAC
Frequency 48.1 - 51.9 Hz or 57.6 - 62.4 Hz; auto sensing
Input connector IEC320-10A IEC320-10A IEC320-16A
OUTPUT AC PARAMETERS
Output Sockets (4) IEC320-10A (4) IEC320-10A (4) IEC320-10A;
(1) IEC320-16A
Voltage 208/220/230/240 (switch selectable) VAC; ±3%
Frequency 50 Hz or 60Hz
Waveform Sinewave
Main Mode Overload 200% for 8 cycles; 130% for 10 seconds with transfer to bypass
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Qty. x Voltage x Rating 4 x 12V x 7 or 7.2 AH 8 x 12V x 6.5 or 7.0 AH 8 x 12V x 7 or 7.2 AH
Back-up Time See Typical Battery Discharge Curves
ENVIROMENTAL
Operating Temperature 0° C to +40° C (+32° F to +104° F)
Storage Temperature -15° C to +50° C (+5° F to +122 °F)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 3000 m (10,000 ft.) at 40° C without derating
Storage Elevation 15.000 m (50,000 ft.) maximum
Audible Noise <50 dBA, at 1 meter
AGENCY
Safety EN50091-1, TUV/GS Listed, CE Low Voltage Directive compliant
RFI/EMI EN55022, Class B; CE EMC Directive compliant
Immunity
IEC 801-2, Level 4 / IEC 801-3, Level 3 / IEC 801-4, Level 4 / IEC801-5,Level 3
