Liebert HPSE User Manual

Mechanical Specifications
3--4
Liebert HPS---PD--- 272965---20.11.2009
F i g . 1 --- HPSE ceiling mounted --- Operating diagram (without freecooling)
ITEM DESCRIPTION
1 Evaporating coil
2 Fan
F i g . 2 --- HPSE ceiling mounted --- Operating diagram (with freecooling)
ITEM DESCRIPTION
1 Fresh air filter
2Evaporatingcoil
3Fan
4 Fan nozzle
5
Freecooling damper
TOP VIEW
(WITHOUT PANEL)
CROSS
SECTION
Return air
Treated air
Return
air
1
2
Return
air
Return air
Freecooling air
TOP VIEW
(WITHOUT PANEL)
CROSS
SECTION
Treated air
Freecooling
air
12 3 45
