Liebert HPSE User Manual

Dimensional Drawings
Liebert HPS---PD--- 272965---20.11.2009
8--5
Fig. 8 --- Evaporating unit SE 06W (version with freecooling)
Condensate drain Condensate drain
N.6 HOLES 4 8
250 800
35060 350 40
310
Circular ducts version
310
185 125
N.2 COLLARS 4 200 HEIGHT 35 mm COLLAR 190 X 560 HEIGHT 35 mm
310
90 190 30
Rectangular duct version
83412 12
800 2929
1050
300 280220 560 15090
BOTTOM VIEW BOTTOM VIEW
REAR VIEW SIDE VIEW
TOP VIEW
Refrigerant outlet
Refrigerant inlet
Refrigerant outlet
Refrigerant inlet
Electrical connections
