Liebert HPSE - Page 18

Technical Data
7--3
Liebert HPS---PD--- 272965---20.11.2009
Ta b . 3 --- HPSE + HPSC (Freecooling and DC emergency freecooling versions)
MODEL: H PS 06 08
Air supply --- Downflow
Main power supply --- 230V±10% / 1Ph / 50Hz 4000V±10%/3Ph+N+PE/5Hz
Emergency power supply --- 48 VDC
PERFORMANCE
Total cooling capacity
(1)
Sensible cooling capacity
(1)
Compressor --- AC power input
(1)
Compressor --- AC operative current (OA)
(1)
Compressor --- AC max current (FLA)
Compressor --- AC starting current (LRA)
Condenser fan --- AC power input
(1)
Condenser fan --- AC max. power input
Condenser fan --- AC operative current (OA)
(1)
Condenser fan --- AC max. current (FLA)
C o n d e n s e r f a n --- A C s t a r t --- u p c u r r e n t
Evaporator fan --- DC power input
(1)
Evaporator fan --- DC operative current (OA)
(1)
Evaporator fan --- DC max. current (FLA)
(2)
Evaporator fan --- DC start--- up current
Evaporator air flow
Freecooling air flow
Condenser max. air flow
Outdoor Sound Pressure Level
(3)
Indoor Sound Pressure Level
(3)
Max. ambient temperature
(4)
kW
kW
kW
A
A
A
kW
kW
A
A
A
kW
A
A
A
m
3
/h
m
3
/h
m
3
/h
dB(A)
dB(A)
_C
5.9
5.9
1.57
7.3
11.4
47.0
0.08
0.08
0.6
1.4
1.6
0.10
2.6
2.6
0.1
1350
820
2170
50
57
48
8.2
8.2
2.17
3.9
5.1
32.0
0.10
0.10
0.7
1.4
1.6
0.28
5.8
9.6
0.1
1910
2040
1920
50
62
45
REFRIGERATION CIRCUITS
Compressor --- type / quantity
Refrigerant
Expansion device
Evaporator coil --- tubes / fins material
Condenser coil --- tubes / fins material
---
---
---
---
---
Scroll / 1
R407C
Capillary
Copper / Aluminium
Copper / Aluminium
AIR FILTRATION
Main air filter --- quantity / type
Efficiency (CEN --- EU)
---
---
3 / Panel filters for DX side --- 1 / Plated panel filter for FC side
G3
Filters dimensiond (DX side) mm 597 / 267 / 10 697 / 332 / 10
Filters dimensiond (FC side) mm 580 / 300 / 50 680 / 365 / 50
EVAPORATOR FAN
Q u a n t i t y / Ty p e / P o l e s --- 1 / P l u g / ---
Driven / Motor protection --- Direct / IP42 Direct / IP20
CONDENSER FAN
Quantity / Type / Poles --- 1 / Axial / 6
Driven / Motor protection --- Direct / IP54
Control system --- Single speed
ELECTRIC HEATING
Type / Steps --- Wires / 1
Heating capacity kW 1.5 3.0
H e a t i n g --- m a x . c u r r e n t A 6 . 5
CABINET
Frame --- Galvanised steel
Painting --- Polyester --- RAL7035
OVERALL DIMENSIONS
Width / Height / Depth (HPSC outdoor unit) mm 920 / 840 / 390
Width / Height / Depth (HPSE indoor unit) mm 800 / 310 / 800 900 / 375 / 900
Weight (HPSC outdoor unit) kg 80 82
Weight (HPSE indoor unit) kg 55 63
Notes:
(1) – Indoor reference conditions: 30˚C / 35% R.H. air intake. Outdoor reference conditions: 35˚C. Nominal power supply.
(2) – Values referred to nominal speed (factory set).
(3) --- Measured with max. outdoor temperature at 2 m from the unit, in free field conditions.
(4) --- Maximum outdoor temperature referred to 30˚C / 35% R.H. air intake.
