Technical Data
7--7
Liebert HPS---PD--- 272965---20.11.2009
Ta b . 7 --- SE_W + HPSC (No freecooling version)
MODEL: HPSW 06 08 10 13
(*)
14
Air supply --- Upflow
Main power supply ---
230V±10% /
1Ph / 50Hz
400V ±10% / 3Ph+N+PE / 50Hz
PERFORMANCE
Total cooling capacity
(1)
Sensible cooling capacity
(1)
Compressor --- AC power input
(1)
Compressor --- AC operative current (OA)
(1)
Compressor --- AC max current (FLA)
Compressor --- AC starting current (LRA)
Condenser fan --- AC power input
(1)
Condenser fan --- AC max. power input
Condenser fan --- AC operative current (OA)
(1)
Condenser fan --- AC max. current (FLA)
C o n d e n s e r f a n --- A C s t a r t --- u p c u r r e n t
Evaporator fan --- AC power input
(1)
Evaporator fan --- AC operative current (OA)
(1)
Evaporator fan --- AC max. current (FLA)
(2)
Evaporator fan --- AC start---up current
Evaporator air flow
Condenser max. air flow
Outdoor Sound Pressure Level
(3)
Indoor Sound Pressure Level
(3)
Max. ambient temperature
(4)
kW
kW
kW
A
A
A
kW
kW
A
A
A
kW
A
A
A
m
3
/h
m
3
/h
dB(A)
dB(A)
_C
6.1
5.4
1.75
8.0
11.4
47.0
0.11
0.24
0.8
1.4
1.6
0.26
1.2
1.2
1.8
1510
2970
48.5
55
52
8.3
8.3
2.26
4.0
5.1
32.0
0.10
0.24
0.7
1.4
1.6
0.71
3.2
3.7
7.0
2670
2970
48.5
60
49.5
10.5
10.1
3.08
5.5
7.0
46.0
0.22
0.48
1.5
2.8
3.3
0.71
3.2
3.7
7.0
2670
6300
52.5
60
50.5
13.5
13.2
3.80
6.7
10.0
50.0
0.23
0.48
1.5
2.8
3.3
1.14
4.8
7.2
---
3950
5675
53.5
62
49
14.7
13.6
4.76
8.7
10.2
63.0
0.28
0.48
1.7
2.8
3.3
1.14
4.8
7.2
---
3950
5675
55.0
62
49
REFRIGERATION CIRCUITS
Compressor --- type / quantity
Refrigerant
Expansion device
Evaporator coil --- tubes / fins material
Condenser coil --- tubes / fins material
---
---
---
---
---
Scroll / 1
R407C
Thermostatic expansion valve
Copper / Aluminium
Copper / Aluminium
AIR FILTRATION
Main air filter --- quantity / type
Efficiency (CEN --- EU)
---
---
1/Pleated
G3
Filters dimension mm 740/230/48 946 / 300 / 60
EVAPORATOR FAN
Quantity / Type / Poles --- 2 coupled (single motor) / Centrifugal / 4
2(2motors)
/Centrifugal
/4
Driven --- Direct
CONDENSER FAN
Quantity/Type/Poles --- 1/Axial/6 2/Axial/6
Driven / Motor protection --- Direct / IP54
Control system --- Variable speed
ELECTRIC HEATING
Type / Steps --- Tube / 1 Wires / 1
Heating capacity kW 3.0 6.0
H e a t i n g --- m a x . c u r r e n t A 6 . 5 8 . 7
CABINET
Frame --- Galvanised steel
Painting --- Polyester --- RAL7035
OVERALL DIMENSIONS
Width / Height / Depth (HPSC outdoor unit) mm 920 / 840 / 390 920 / 1190 / 390
Width / Height / Depth (SE_W indoor unit) mm 800/310/800 1100 / 395 / 1095
Weight (HPSC outdoor unit) kg 80 82 97 103 111
Weight (SE_W indoor unit) kg 54 110
120
Notes:
(1) – Indoor reference conditions: 27˚C / 47% R.H. air intake. Outdoor reference conditions: 35˚C. Nominal power supply.
(2) – Values referred to nominal speed (factory set).
(3) --- Measured with outdoor temperature o f 35˚C, at 2 m from the unit, in free field conditions.
(4) --- Maximum outdoor temperature referred to 27˚C / 47% R.H. air intake.
(*) --- HPSW 13 is composed by SE 13W + HPSC 12.
