Dimensional Drawings
8--9
Liebert HPS---PD--- 272965---20.11.2009
Fig. 12 --- Condensing unit HPSC 06--08
A
132 656 132
390
354
80535
390
338
1818
920
840
A
REAR VIEW
SIDE VIEW
FRONT VIEW
Refrigerant
outlet
Refrigerant
inlet
Refrigerant
outlet
Refrigerant
inlet
Electrical
connections
A --- A S e c .
