Liebert UPS System User Manual

Chapter 3 Electrical Assembly
27
Input power cable
Parallel power cable
Wire terminal
Fig. 3-3 Power cable connection of One branch utility source
5. Connect the Load to the U, V, W terminals of UPS output breaker Q5.
6.Connection of battery cables
The positive and negative cables of batteries are connected to the Positive and
Negative terminals of JX3 respectively.
7. Connection of Neutral cable
The neutral cable of bypass source is connected to the JX5 copper bar, that is
marked with “N/INPUT”. The neutral cable of UPS output source is connected to
copper bar JX4, that is marked with “N/OUTPUT”.
 Note
The phase rotation of circuit breakers Q1, Q2, Q5 cannot be wrong and the phase
rotation is shown in Figure 3-4.
ABC
RTS
WUV
L1 L3L2
ABC
TRS
UWV
L1 L2 L3
BC
TRS
UWV
L1 L2 L3
L1
U
T
B
W
L2
A
V
SR
L3
C
S
L3
R
C
B
U
A
L1
R
L1
C
ST
U
A
W
W
V
L2
B
T
L2
V
L3
A
Q1 Q2 Q5
Fig. 3-4 Phase rotation
