LAY OUT THE TREADMILL PARTS AND HARDWARE
1. Place the folded body of the treadmill on a flat floor.
2. Place all of the hardware and tools nearby.
1
ASSEMBLE THE UPRIGHT POSTS
1. Lift both upright posts up at the same time.
2. Use four M8x16 mm bolts (50), two curved washers (57), and
two flat washer (46) on the base of the posts to fix both upright
posts in the upright position.
2
ATTACH THE CONSOLE
1. First connect the cables on the right side as in the diagram
below.
2. Then remove the two M6x30 bolts (55) and M6 nuts (54)
from the console and use the same bolts and nuts to affix
the console on the upright post.
3. Use two M8x16 bolts (50) and two curved washers (57) to
affix the console on the upright post tightly as seen below.
3
10 EcoStride User Manual Lifepro Endurance Training Collection 11
TREADMILL SETUP GUIDE (Continued)
5046 57
50
50
57
55
54
