ATTACH THE PEDALS
TO THE BIKE FRAME
1. Identify the left and right pedals (36 R/L) (labeled L and R). Identify
the left and right crank arms (35 R/L).
2. Screw the right pedal (36 R) CLOCKWISE onto the right crank
arm (35 R).
3. Use the multi-tool (40) to fully tighten the pedal.
4. Screw the left pedal (36 L) COUNTER-CLOCKWISE onto the left crank
arm (35 L).
5. Use the multi-tool to fully tighten the pedal.
CAUTION: Be careful not to mix up the left and right pedals.
CAUTION: Be sure to completely tighten the pedals and pedal nuts.
Riding the bike with loose pedals can cause injury and/or strip the pedals.
ATTACH THE WATER
BOTTLE HOLDER
1. Remove the two water bottle holder screws (38) from the right side of
the bike frame.
2. Align the holes in the water bottle holder (37) with the screw holes in
the bike frame.
3. Insert the two screws to secure the water bottle holder in place.
4. Use the multi-tool (40) to tighten the screws.
11 12
Endurance Training Collection 21 20 VeloCycle User Manual Lifepro Endurance Training Collection 21
Front of
Bike
36 R
36 L
35 R
35 L
37
38
38
TOOLS & HARDWARE
(40)
(38) x2
TOOLS & HARDWARE
(40)
