lifeSMART 2+ LS-946 - Display Screen; Test Strip

11
Display Screen
1
Ketone Symbol / Ketone Warning
11
2
Glucose Level / Ketone Level
12
3
Error Warning
13
4
Low Battery Symbol
14
5
Day Average
15
6
Memory Symbol
7
Time / Date
8 HCT Level
9 Glucose / Ketone Measurement
Unit
10
Measurement Modes
Gen – any time of day
AC – before meal
PC – after meal
Test Strip Symbol
Blood Drop Symbol
Code
Glucose Symbol
Alarm reminder
Test Strip
1
Absorbent Hole
3
2
Confirmation Window
4
ATTENTION:
Test Strip Handle
Contact Bars
(for glucose test) (for ketone test)
The front side of test strip should
face up when inserting test strip.
Test results may be wrong if the contact
bar is not fully inserted into the test slot.
NOTE:
The LS-946 monitor should only be used with LS-946 Glucose or β-Ketone
Test Strips. Using other test strips with this meter can produce inaccurate
results.
1
2
3
4
13 12 11
14
1
10
2
15
3
4
5
6
9
8
7
